HCP-6320A Hanwha Vision 4.44-142.6mm 32x Optical Zoom 30FPS @ 1080p Indoor Day/Night WDR PTZ AHD/Analog Security Camera 24VAC

Specifications

Video

• Imaging Device - 1/2.8" 2.38MP CMOS
• Resolution - 1920x1080
• Min. Illumination - Color: 0.3 Lux (1/30sec, F1.6, 50IRE) , 0.005 Lux(2sec, F1.6, 50IRE) B/W: 0.03 Lux (1/30sec, F1.6, 50IRE), 0.0005 Lux(2sec, F1.6, 50IRE) Color: 0.2 Lux (1/30sec, F1.6, 30IRE), 0.003 Lux(2sec, F1.6, 30IRE) B/W: 0.01 Lux (1/30sec, F1.6, 30IRE), 0.0001 Lux(2sec, F1.6, 30IRE)
• Video Out - BNC(AHD), CVBS(SD, DIP connector type)

Lens

• Focal Length (Zoom Ratio) - 4.44 ~ 142.6mm(32x) motorized varifocal
• Optical Zoom Ratio - 32x
• Max Aperture Ratio - F1.6(Wide) ~ F4.4(Tele)
• Min. Object Distance - Wide : 1.5m (4.92ft), Tele : 2m (6.56ft)
• Focal Control - Auto / Manual / One push
• Lens Type - DC auto iris

Pan / Tilt / Rotate

• Pan Range - 360° Endless
• Pan Speed - Preset: 700°/sec, Manual: 0.024°/sec~200°/sec
• Tilt Range - 210°(-15° ~195° )
• Tilt Speed - Preset : 700°/sec, Manual : 0.024°/sec~200°/sec
• Preset Accuracy - ±0.2°

Operational

• Camera Title - Displayed up to 12 characters
• Day & Night - Auto(ICR)
• Backlight Compensation - BLC, HLC, WDR
• Wide Dynamic Range (dB) - 120dB
• Digital Noise Reduction - SSNRâ…¢
• Digital Image Stabilization - Support
• Defog - Support
• Motion Detection - 1ea, rectangular zone
• Privacy Masking - 12ea, rectangular zones
• Gain Control - Low / Middle / High
• White Balance - ATW / AWC / Manual / Indoor / Outdoor
• Electronic Shutter Speed - ESC / Auto / Manual
• Video Rotation - Digital Flip
• Analytics - Motion detection, Appear/Disappear, Enter/Exit, Virtual Line
• Serial Interface - RS-485: Samsung-T/E, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell
• Alarm I/O - Input 4ea, Output 2ea
• Alarm Triggers - Analytics
• Alarm Events - Alarm output
• Coaxial Protocol - ACP(AHD Coax Protocol)

Environmental & Electrical

• Operating Temperature/Humidity - -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH
• Storage Condition Temperature - -50°C ~ +60°C (-58°F ~ +140°F)
• Storage Condition Humidity - Less than 90% RH
• Certification - IK10
• Input Voltage - 24VAC
• Power Consumption - Max 20W

Mechanical

• Color - Ivory
• Material - Plastic
• Product Dimensions - Ø152.0x218.0mm(Ø5.98"x8.58")
• Product Weight - 2200g(4.85lb)

Ver

• Ver - 2024.07

HCP-6320A Specifications PDF
