[DISCONTINUED] AE-23D Vivotek Outdoor Enclosure 24VAC/VDC

Supreme Series outdoor enclosures are compatible with all VIVOTEK box cameras, including wide-angle lenses or long-distance remote focus lenses. The camera enclosures areconstructed from cast aluminum to meet IP68, and IK 10 standards.
AE-23A, AE-23B, AE-23C and AE-23D are supported by 24VAC/VDC input, AE-23E and AE-23F are supported by PoE input, AE-23B, AE23D and AE-23F are designed with built-in wiper. AE-23C and AE-23D support cold start heater. All of the modelsare equipped with demisting windows heater & fan and alsosupport side-opening alarm switch, adjustable sunshield andoptional VAIR (Vari-Angle IR) illuminator.

Specifications

• Input Voltage- 24VAC/VDC
• Max Output Power Budget- 100W
• Power Consumption-
  • Window Heater: 10W
  • Blower: 2W
  • Camera: 6 ~ 8W
  • Others: 2W
  • Cold Start Heater:30W
• Optional Vari IR Illuminators Power consumption-
  • AI-106 : 6W
  • AI-107: 12W
  • AI-109: 48W
• Operating Temperature-
  • -50°C ~ 65°C
  • (-58°F ~ 149°F)
  • Cold Startup:-40°C (-40°F)
• Windows Heater ON/OFF-
  • ≤ 30°C (86°F) ON
  • ≥ 35°C (95°F) OFF
• Cold Start Heater ON/OFF-
  • ≤ 0°C (32°F) ON
  • ≥ 5°C (41°F) OFF
• Fan ON/OFF-
  • ≥40°C (104 °F) ON
  • ≤ 35°C (95 °F) OFF
• Waterproof IP Rating- IP68
• Vandal Proof-
  • IK10
  • Impact Rated on
  • Cast
  • Aluminum
  • Housing
• Supported Cameras-
  • All VIVOTEK Box
  • Cameras



  AE-23D Specifications PDF
