[DISCONTINUED] FD8182-F1-B Vivotek 1.96mm 15FPS @ 5MP Indoor Dome IP Security Camera 12VDC/PoE - Black

Specifications

System Information

• CPU - Multimedia SoC (System-on-Chip)
• Flash - 1Gb
• RAM - 4Gb

Camera Features

• Image Sensor - 1/3.2" Progressive CMOS
• Maximum Resolution - 2560x1920 (5MP)
• Lens Type - Fixed-focal
• Focal Length - f = 1.96 mm
• Aperture - F2.2
• Field of View
  • 137° (Horizontal)
  • 101° (Vertical)
  • 180° (Diagonal)
• Shutter Time - 1/5 sec. to 1/32,000 sec.
• WDR Technology - WDR Enhanced
• Minimum Illumination - 0.58 Lux @ F2.2 (Color)
• Pan/tilt/zoom Functionalities - ePTZ: 48x digital zoom(4x on IE plug-in, 12x built in)
• On-board Storage - Slot type: MicroSD/SDHC/SDXC card slot Seamless Recording

Video

• Compression - H.264 & MJPEG
• Maximum Frame Rate
  • 15 fps @ 2560x1920
  • 15 fps @ 2048x1536
  • 30 fps @ 1920x1080
  • In both compression modes
• Maximum Streams - 4 simultaneous streams
• S/N Ratio - 67 dB
• Dynamic Range - 70 dB
• Video Streaming - Adjustable resolution, quality and bitrate; Smart Stream
• Image Settings - Adjustable image size, quality and bit rate, Time stamp, text overlay, flip & mirror, Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks, Scheduled profile settings, 3D noise reduction, video rotation, defog

Audio

• Audio Capability - Two-way Audio (full duplex)
• Compression - G.711, G.726
• Interface
  • Built-in microphone
  • External line input
  • External line output

Network

• Users - Live viewing for up to 10 clients
• Protocols - IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/ RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, SSL, TLS, CIFS/SMB
• Interface
  • 10 Base-T/100 BaseTX Ethernet (RJ-45)
  • It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
• ONVIF - Supported, specification available at www.onvif.org

Intelligent Video

• Video Motion Detection - Five-window video motion detection

Alarm and Event

• Alarm Triggers - Motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection, audio detection
• Alarm Events
  • Event notification using digital output, HTTP, SMTP, FTP, NAS server and MicroSD Card
  • File upload via HTTP, SMTP, FTP, NAS server and MicroSD card

General

• Connectors
  • RJ-45 cable connector for Network/PoE connection
  • Audio input
  • Audio output
  • DC 12V power input
  • Digital input 1
  • Digital output 1
• LED Indicator - System power and status indicator
• Power Input
  • DC 12V
  • IEEE 802.3af/at PoE Class 0
• Power Consumption - Max. 9 W
• Dimensions - Ø 138 x 103 mm
• Weight - 482 g
• Safety Certifications - CE, LVD, FCC Class B, VCCI, C-Tick
• Operating Temperature
  • Starting Temperature: 0°C ~ 50°C (32°F~ 122°F)
  • Working Temperature: -10°C ~ 50°C (14°F~ 122°F)
• Humidity - 90%
• Warranty - 24 months

System Requirements

• Operating System - Microsoft Windows 7/8
• Web Browser
  • Mozilla Firefox 7~43 (streaming only)
  • Internet Explorer 10/11
• Other Players
  • VLC: 1.1.11 or above
  • Quicktime: 7 or above

Included Accessories

• CD - User's manual, quick installation guide, Shepherd, VAST 32-channel recording software
• Others - Quick installation guide, warranty card, alignment sticker/desiccant bag, screw pack

FD8182-F1-B Specifications PDF
