[DISCONTINUED] M1211-MPW2-R Computar 2/3" C Mount 12mm F11.0 5MP Fixed Iris Lens

Specifications

• Model No. - M1211-MPW2-R
• Focal Length - 12mm
• Max. Aperture Ratio - 1:11.0
• Max. Image Format - 8.8mm x 6.6mm(φ11mm)
• Effective Lens Aperture
  • Front - φ19.5mm
  • Rear - φ13.5mm
• Distortion
  • 2/3 type - --0.05%(y=5.5)
  • 1/1.8 type - -0.34%(y=4.32)
  • 1/2 type - -0.35%(y=4.0)
• Operation Range
  • Iris - F2.4/F4.0/F5.6/F8.0/F11.0
  • Focus - 0.05m ‐ Inf.
  • Back Focal Length - 14.39mm
• Control
  • Iris - Fix
  • Focus - Manual
  • Flange Back Length - 17.526mm
  • Mount - C-Mount
• Object Dimension at M.O.D.
  • 2/3 Type - 6.4cm x 8.5cm
  • 1/1.8 Type - 5.0cm x 6.7cm
  • 1/2 Type - 4.6cm x 6.2cm
  • Filter Size - M25.5 P=0.5mm
  • Dimensions - φ28mm x 42.7mm
  • Weight - 59g
• Angle of View
  • 2/3 Typee
  • D - 48.6°
  • H - 39.8°
  • V - 30.4°
  • 1/1.8 Type
    • D - 39.1°
    • H - 31.7°
    • V - 24.0°
  • 1/2 Type
    • D - 36.5°
    • H - 29.5°
    • V - 22.3°
• Operating Temperature - -10°C ‐ +50°C
