M3580-MPW2-R Computar 2/3" C Mount 35mm F8.0 5MP Fixed Iris Lens

Specifications

• Model No. - M3580-MPW2-R
• Focal Length - 35mm
• Max. Aperture Ratio - 1:2.0
• Max. Image Format - 8.8mm x 6.6mm(φ11mm)
• Effective Lens Aperture
  • Front - φ18.0mm
  • Rear - φ12.0mm
• Distortion
  • 2/3 type - 0.011%(y=5.5)
  • 1/1.8 type - 0.010%(y=4.32)
  • 1/2 type - 0.009%(y=4.0)
• Operation Range
  • Iris - F2.0/F4.0/F5.6/F8.0/F11.0
  • Focus - 0.2m ‐ Inf.
  • Back Focal Length - 18.0mm
• Control
  • Iris - Fix
  • Focus - Manual
• Flange Back Length - 17.526mm
• Mount - C-Mount
• Object Dimension at M.O.D.
  • 2/3 Type - 3.48cm x 4.63cm
  • 1/1.8 Type - 2.74cm x 3.63cm
  • 1/2 Type - 2.53cm x 3.37cm
• Filter Size - M25.5 P=0.5mm
• Dimensions - φ28mm x 35.17mm
• Weight - 45g
• Angle of View
  • 2/3 type
  • D - 17.8°
  • H - 14.3°
  • V - 10.7°
  • 1/1.8 Type
    • D - 14.0°
    • H - 11.2°
    • V - 8.5°
  • 1/2 Type
    • D - 13.0°
    • H - 10.4°
    • V - 7.8°
• Operating Temperature - -10°C ‐ +50°C
