LW-22E AG Neovo 22" LED Monitor w/ Speakers 1920 x 1080 HDMI/VGA/DisplayPort

Specifications

Panel

• Panel Type - LED-Backlit TFT LCD (TN Technology)
• Panel Size - 21.5"
• Max. Resolution - FHD 1920 x 1080
• Pixel Pitch - 0.248 mm
• Brightness - 250 cd/m2
• Contrast Ratio - 20,000,000:1 (DCR)
• Viewing Angle (H/V) - 170°/160°
• Display Colour - 16.7M
• Response Time - 3 ms

Frequency (H/V)

• H - 30 kHz - 95 kHz
• V - 48 Hz - 76 Hz

Input

• Display Port - x 1
• HDMI - 1.4 x 1
• VGA - 15-Pin D-Sub x 1

Audio

• Audio In - Stereo Audio Jack (3.5 mm) x 1
• Audio Out - Stereo Audio Jack (3.5 mm) x 1
• Speaker - 2W x 2

Power

• Power Supply - Internal
• Power Requirements - AC 100-240V, 50/60 Hz
• On Mode - 19W (On)
• Stand-by Mode - < 0.5W
• Off Mode - < 0.5W

Operating Conditions

• Temperature - 32°F-104°F
• Humidity - 10%-85% (non-condensing)

Storage Conditions

• Temperature - -13°F-131°F
• Humidity - 10%-85% (non-condensing)

Mounting

• VESA FPMPMI - Yes (100 x 100 mm)

Stand

• Tilt - -4° ~ +18°

Security

• Kensington Security Slot - Yes

Dimensions

• Product (W x H x D) - 19.9" x 14.4" x 7.1"
• Packaging(W x H x D) - 23.2" x 16.3" x 11.1"

Weight

• Product Weight - 7.1 lbs
• Packaged Product Weight - 11.4 lb

Regulation Approval

• Certifications & Compliance - FCC, CE, CB, BSMI, WEEE, RoHS, REACH

Accessories

• Supplied - Power Cord, VGA Cable, Audio Cable, Quick Start Guide, Warranty Card
• Optional Accessories - Wall Mount: PMK-01 Desk Mounts: DMC-01, DMC-02D, DMS-01D, DMS-01Q, ES-02 Ceiling Mount (Landscape only): CMP-01 + WMK-03 Wall Mounts (Landscape only): WMA-01, WMK-01, WMK-03
