[DISCONTINUED] FD9387-HV Vivotek 2.8mm 30FPS @ 5MP Indoor/Outdoor IR Day/Night WDR Dome IP Security Camera 12VDC/24VAC/PoE

VIVOTEK FD9387 is a series of outdoor dome network camera offering up to 30 fps @ 5-Megapixel or 60 fps @ full HD sensor with superb image quality at all resolutions or frame rates. And FD9387 Series also supports standard 1920x1080 resolution at 60 frames per second. Featuring VIVOTEK SNV and WDR Pro technology, FD9387 Series is capable of capturing high quality image whether in high contrast or low light environment.

Specifications

Model - FD9387-HV : Fixed-focal

System Information

• CPU - Multimedia SoC (System-on-Chip)
• Flash - 256MB
• RAM - 1GB

Camera Features

• Image Sensor - 1/2.7"" Progressive CMOS
• Max. Resolution - 2560 x 1920 (5MP)
• Lens Type - Fixed-focal
• Focal Length - 2.8 mm
• Aperture - F2.0
• Auto-Iris - Fixed-Iris
• Field of View - 103° (Horizontal), 76° (Vertical), 134° (Diagonal)
• Shutter Time - 1/5 sec. to 1/32,000 sec
• WDR Technology - WDR Pro
• Day/Night - Yes
• Removable IR-cut filter - Yes
• Minimum Illuminators - 0.06 Lux @ F2.0 (Color) <0.01 lux, F2.0 (B/W) 0 Lux with IR illumination on
• Pan Range - 350°
• Tilt Range - 80°
• Rotation Range - 180°
• Pan/Tilt/Zoom Functionalities - ePTZ:48x digital zoom (4x on IE plug-in, 12x built-in)
• IR Illuminators - Built-in IR illuminators up to 30 meters with Smart IR, IR LED*2
• On-board Storage - Slot type : MicroSD/SDHC/SDXC card slot Seamless Recording

Video

• Compression - H.265, H.264, MJPEG
• Maximum Frame Rate - 30 fps @ 2560x1920, 60 fps @ 1920x1080
• Maximum Streams - 3 simultaneous streams
• S/N Ratio - 54 dB
• Dynamic Range - 120 dB
• Video Streaming - Adjustable resolution, quality and bitrate, Smart Stream III
• Image Settings - Time stamp, text overlay, flip & mirror; Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks; Scheduled profile settings, video rotation, 3DNR, DIS, HLC

Audio

• Audio Capability - Two-way Audio (full duplex)
• Compression - G.711, G.726
• Interface - Built-in microphone External microphone input External line output

Network

• Users - Live viewing for up to 10 clients
• Protocols - IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, CIFS/SMB, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, SSL/TLS
• Interface - 10 Base-T/100 Base-TX Ethernet (RJ-45) *It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard..
• ONVIF - Supported, Specification available at www.onvif.org

Intelligent Video

• Smart Motion Detection - Five-window video motion detection, people detection, time filter
• VCA - Standard VCA (optional)
  *Including line crossing detection, field detection, loitering detection
• VADP Package - Genetec Package, Trend Micro IoT Security, mart Motion Detection

Alarm and Event

• Alarm Triggers - Motion detection, manual trigger, periodical trigger, system boot, recording notification, camera ampering detection, audio detection, MicroSD card life expectancy, shock detection, cybersecurity events (block brute force attack, block cyber attack, quarantine event)
• Alarm Events - Event notification using HTTP, SMTP, FTP, NAS server and MicroSD card File upload via HTTP, SMTP, FTP, NAS server and MicroSD card

General

• Connectors - RJ-45 cable connector for 10/100Mbps Network/PoE connection, Audio line input, Audio line output, AC 24V power input (optional), DC 12V power input, Digital input *1, Digital output *1
• LED Indicator - System power and status indicator
• Power Input - IEEE 802.3af PoE Class 0
• Power Consumption - PoE: Max. 8.1 W, DC 12V: Max. 7.4 W AC 24V : Max. 7.5 W
• Dimensions - 155 x 104 mm
• Weight - 909 g
• Casing - IP66, IP67, IK10 (Metal Housing)
• Safety Certifications - CE, FCC Class B, UL, LVD, VCCI, C-Tick
• Operating Temperature - Starting Temperature : -10°C ~ 60°C (14°F ~ 140°F), Working Temperature : -30°C ~ 60°C (-22°F ~ 140°F)
• Humidity - 90%
• Warranty - 36 months

System Requirements

• Operating System - Microsoft Windows 8/7
• Web Browser - Mozilla Firefox 7~43 (streaming only) Internet Explorer 10/11
• Other Players - VLC : 1.1.11 or above, QuickTime: 7 or above

Included Accessories

• Others - Quick installation guide, warranty card, alignment sticker, screw pack, conduit ring

FD9387-HV Specifications PDF
