ELK-319HRR ELK Wireless Heat Rate of Rise Sensor 319.5MHz - Selectable Setpoint of 135°F or 200°F

Search available promotions and discounts for this Item

SKU: ELK-319HRR

Brand: ELK

Ideal for garages, kitchens, attics, utility closets, etc.
Long range and battery life
Transmits alarm, tamper, low battery, and supervisory signals
Selectable setpoint of either 135°F or 200°F
Common replacement for Interlogix HDX-135
Powered by a single CR123 battery
For 345MHz radio frequency add the 2GIG-DREC2-319 dual receiver shown below
Includes: Heat Sensor, (1) CR123 Battery, Mounting Hardware, Instructions

More details...

Search available promotions and discounts for this Item

MPN: ELK-319HRR
UPC: 762158190117

MSRP Price: $100.00

Online Price: $68.77

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

The ELK-319HRR is a Supervised, Wireless Heat Sensor. It uses a solid-state thermistor to sample and trigger an event at a selectable setpoint of either 135 or 200 degrees F. It can also trigger an event if the temperature rises 12 degrees F or more during a one (1) minute time period.

Specifications

RF frequency - 319.5 MHz
Supervision Interval - 62 - 68 minutes
Compatibility - ELK-319 Receivers/Panels & other panels that operate on the 319.5MHz Freq. and adhere to the ITI/Interlogix protocol
Battery type - One (1) 3VDC lithium battery (Panasonic or Varta Model CR123) Exp. Battery life 10 yrs
Rate of Rise Rating - 12° to 15°F (6.7° to 8.3°C)
UL max. Ambient ceiling - 100°F/150°F (37.8°C/65.6°C
Maximum UL Spacing - 50ft (15.2m) x 50ft (15.2m)
Storage Temp Range - -30 to 167°F (-34 to 75°C)
Relative Humidity - 0 to 95% non-condensing
Dimensions - 2.29" Dia. x 1.28" H (58.25mm x 32.4mm)

ELK-319HRR Specifications PDF
