TL-D400S-US QNAP 4-Bay Desktop SATA JBOD Expansion Unit

TL-D400S JBOD storage enclosure allows you to back up and expand your QNAP NAS, Windows and Ubuntu computers and servers. The TL-D400S features four 3.5-inch SATA 6Gb/s drive bays and comes with a QXP PCIe card for connecting the enclosure using a SFF-8088 (or SFF-8644) cable. It provides reliable read/write performance for smooth storage and backup tasks.

Specifications

• Drive Bay - 4 x 3.5-inch SATA 6Gb/s, 3Gb/s
• Drive Compatibility
  • 3.5-inch SATA hard disk drives
  • 2.5-inch SATA hard disk drives
  • 2.5-inch SATA solid state drives
• Audio Alert On/Off Switch - Yes
• Form Factor - Tower
• Host Interface - 1 x SFF-8088
• LED Indicators - HDD 1-4, Status, Link, Fan error
• Buttons - Power switch
• Dimensions (HxWxD) - 6.63 x 6.31 x 8.62 inch
• Weight (Net) - 8.07 lbs
• Max. number of HDDs/SSDs supported - 4
• Hard Drive Type
  • 3.5-inch SATA hard disk drives
  • 2.5-inch SATA hard disk drives
  • 2.5-inch SATA solid state drives
• Operating temperature - 0 - 40 °C (32°F - 104°F)
• Relative Humidity - 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
• Power Supply Unit - 65W adapter, 100 - 240V
• Power Consumption: Operating Mode, Typical - 22.985 W
• Fan Mode Switch - Yes (Auto, high, medium, low)
• Fan - 1 x 120mm, 12VDC
• Sound Level - 20.1 db(A)
• System Warning - Buzzer
• Kensington Security Slot - Yes

TL-D400S-US Specifications PDF
