ADC-CSVR126-16CH-1x2TB Alarm.com CSVR126 16 Channel NVR 160Mbps Max Throughput - 2TB

Designed specifically to work with the Alarm.com hosted video service, the ADC-CSVR126 Stream Video Recorder provides a 24x7 professional solution for commercial-grade local video storage. With the Stream Video Recorder, you can associate up to 16 Alarm.com video cameras for continous recording.

Specifications

• Recording Channels - Up to 16 cameras
• Video Input - 16 channels @ 1080p
• Incoming Bandwidth - 160 Mbps
• Outgoing bandwidth - 256 Mbps
• HDMI Max Output - 4K (3840 x 2160) 60 Hz
• VGA Max Output - Full HD (1920 x 1080) 60 Hz
• Local Display Capabilities - Live View, Playback, Clip Export
• Compatible Cameras - ADC-V522IR, ADC-V523, ADC-V622, ADC-V722W, ADC-V723, ADC-VC725, ADC-VC726, ADC-VC736, ADC-VC825, ADC-VC826, and ADC-VC836
• Speed Control - 1x, 4x, 8x
• Hard Disk Drive (HDD) - 2 SATA interfaces, up to 8 TB per interface
• Ethernet Connection - RJ-45 10 / 100 / 1000 Mbps self-adaptive Ethernet interface
• USB Interface - 1 x USB 2.0; 1 x USB 3.0
• Power Adapter - 12 V DC ≤ 40 W
• Dimensions - 15.2 x 12.4 x 2.0" (385 x 315 x 52 mm)
• Operating Temp - 14°F - 131°F (-10°C - 55°C)
• Operating Humidity - 10% - 90% (non-condensing) RH
• Weight (Without HDD) - ≤2.2 lbs. (1 kg)
• Installation - Rack-mount (1U) compatible
• Compliance - UL Listed

ADC-CSVR126-16CH-1x2TB Specifications PDF
