QSW-IM1200-8C-US QNAP Rackmount Switch, Management Switch, 12 Port of 10GbE Port Speed, 4 10GbE SFP+ Port, 8 Port SFP+/ NBASE-T Combo, Support for 5-Speed Auto Negotiation (10G/5G/2.5G/1G/100M)

Search available promotions and discounts for this Item

SKU: QSW-IM1200-8C-US

Brand: QNAP

With an industrial hardened IP20 metal case, fanless design and ventilated construction, the QSW-IM1200-8C can operate in temperatures of -30 ~ 65° Celsius. The redundant DC power supply and circuit breaker also guarantees continuous operation
The QSW-IM1200-8C is equipped with eight 10GbE SFP+/ RJ45 combo ports. Compatible with 10GbE and NBASE-T technologies to support five speeds (10G / 5G / 2.5G / 1G / 100M), the QSW-IM1200-8C offers higher transmission speeds when used with existing cables
The QSW-IM1200-8C provides Layer 2 management features, such as LACP, VLAN, ACL and LLDP for users to efficiently control network bandwidth and enhance security
Featuring a user-friendly web UI, the QNAP Switch System (QSS) provides an overview dashboard, port management and setting guide, making central industrial network management intuitive and easy
Supports Rapid Spanning Tree Protocol (RSTP). You can easily and efficiently deploy small/medium-scale networks that support expansion, redundancy and loop prevention
Compliant with IEEE 802.3az Energy Efficient Ethernet and IEEE802.3x Flow Control in full-duplex mode, the QSW-IM1200-8C avoids packet loss from unparalleled bandwidth and reduces power consumption for low-speed and inactive connections

More details...

Search available promotions and discounts for this Item

MPN: QSW-IM1200-8C-US
UPC: 885022021246

MSRP Price: $1,099.00

Online Price: $1,099.00

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

The rugged 12-Port 10GbE Managed Switch QSW-IM1200-8C has four 10GbE SFP+ fiber ports, eight 10GbE SFP+/RJ45 combo ports, and supports Layer 2 switching and network management to provide a user-friendly entry-level network management solution. With a robust industrial-grade hardware design and operating temperatures of -30 ~ 65° Celsius in airy environments (0.5~0.7m/s ) or -30 ~ 45° Celsius in enclosed spaces, the QSW-IM1200-8C enables high-speed network deployment in the rugged environments of Industry 4.0, smart transportation, and smart cities.

Specifications

Management Type - Web Managed
Number of Ports - 12
10GbE SFP+ - 4
10GbE SFP+/RJ45 Combo Ports - 8
Management Port - 1 x 1GbE RJ45
Power Supply Description - Adapter
Max. Power Consumption - 78W
Input Power Type - DC
Input Voltage Range - 9V-54V
MAC Address Table - 16K
Total Non-Blocking Throughput - 120Gbps
Switching Capacity - 240Gbps
Management Interface - Web
Console - RS232
Energy Efficient Ethernet (IEEE 802.3az complaint) - Yes
Fanless - Yes
Supported Standards
- IEEE 802.3 Ethernet
- IEEE 802.3u 100BASE-T
- IEEE 802.3ab 1000BASE-T
- IEEE 802.3bz 2.5G/5GBase-T
- IEEE 802.3an 10G BASE-T
- IEEE 802.3z 1000BASE-SX/LX
- IEEE 802.3ae 10G Fiber
- IEEE 802.3x Full-Duplex Flow Control
- IEEE 802.1Q VLAN Tagging
- IEEE 802.1w RSTP
- IEEE 802.3ad LACP
- IEEE 802.1AB LLDP
- IEEE 802.3az Energy Efficient Ethernet
- (IEEE 802.1p Class of Service)
Form Factor - Rackmount
LED Indicators - Per Port: Speed/Link/Activity, Per System: Status/Power1/Power2/Power3
Buttons - Reset button
Dimensions (HxWxD) - 43.5 x 285 x 238 mm
Weight (Net) - 10.1 lbs
Weight (Gross) - 11.71 lbs
Operating Temperature - Natural convection (in airy environments 0.5~0.7m/s) operating temperature -30°C-65°C (-22°F –149°F) in airy environments, Non natural convection operating temperature -30°C-45°C (-22°F –113°F)
Relative Humidity - 5~95% Non-condensing
Certifications - CE, FCC, VCCI, BSMI
Electromagnetic Compliance - Class A
Jumbo Frames - 9K
Warranty - 2 Years

QSW-IM1200-8C-US Specifications PDF
