TCIS-2 Hanwha Vision Outdoor Audio Intercom

Specifications

Audio

• Audio quality - percentage articulation loss of consonants (Alcons) - at 70dB - < 5%*
• Audio quality - total harmonic distortion + noise, without noise reduction (THD+N) - at 70dB - < 2%*
• SPL rated power at 1m in open duplex - 95 dB*
• SPL rated power at 1m in half duplex -105 dB*
• SPL rated power at 1m in program distribution and announcement - 105 dB*
• Noise canceling - YES (Suppression of musical noise, static noise, rapidly changing noise)
• Codecs - G.711, G.722, G.729
• Frequency range, G.722 Codec - 200 Hz - 7000 Hz
• Audio technology - Modes: Full open duplex, switched open duplex | Adaptive jitter buffer | Custom Ringing Tone | Audio Mixing - Conversation and Group Call | Sound Level Detection / scream alarm (only in AlphaCom) | Automatic gain control (microphone)
• Internal speaker amplifier - 10W Class D
• Microphone technology - Digital MEMS, omnidirectional microphone
• Automatic Volume Control (AVC) - Undistorted and clear audio
• Acoustic Echo Cancellation (AEC) - Prevents audio feedback even at high volumes (95dB)
• 10W Speaker - Matches 10W amp for distortion-free broadcast level sound *Tested with Audio Precision SYS 2722 equipment

Hardware

• Ethernet connector - 1 x RJ45
• All other connectors - Tool less, spring loaded, vibration proof terminals
• General inputs and outputs - 6 (configurable)
• Outputs - 12mA as LED drivers
• Change-over relay (NO+NC+COM) - Max: 250VAC / 220VDC, 2A, 60W
• Power options - PoE and or external power supply
• PoE (Power over Ethernet) - IEEE 802.3af standard, Class 0 (0.44W to 12.95W)
• External power supply - 24VDC (16 - 48V)
• Power consumption - Idle 1.8W, max 12W (depending on volume)
• Auido Line out / Induction loop signal - 600 Ohm
• Button backlight - LED
• Call indication - Icons / colors for hearing impaired

Construction

• Dimensions (HxWxD) - 180mm x 120mm x 73mm (7.1" x 4.7" x 2.9")
• Dimensions with flush mount - 180mm x 120mm x 24mm (7.1" x 4.7" x 0.9")
• Dimensions with on wall box - 180mm x 120mm x 86mm (7.1" x 4.7" x 3.4")
• Weight - 1kg / 2.2lbs
• Faceplate material - 3mm / 0.12" stainless steel - AISI 316L
• Base / frame material - 3mm / 0.12" Aluminum alloy - A413.0, AISi12Fe, painted
• Electronics cover material - Polycarbonate (translucent)
• Gasket material - Silicone rubber
• Fastening bracket material - SECC Steel
• Button material - 3mm / 0.12" Polycarbonate (transparent)
• Button travel length - 1.25mm
• Button activation force - 350 gf
• Button push-cycles before failure - 300,000
• Anechoic Design - Open flow anechoic design eliminates "standing waves"
• Loudspeaker poke protection (large diameter object) - 3D cast aluminum speaker grille
• Loudspeaker poke protection (small diameter object) - Stainless steel mesh, acoustically transparent

Networking and Protocols

• Protocols - IPv4 (with DiffServ), SIP, TCP, UDP, HTTPS, TFTP, RTP, SRTP, DHCP, SNMPv2C, Vingtor-Stentofon CColP®, NTP
• LAN protocols - Power over Ethernet (IEEE 802.3 a-f) Network Access Control (IEEE 802.1x)
• Management and operation - HTTP/HTTPS (Web administration and configuration) DHCP and static IP. Remote automatic software upgrade. Centralized monitoring
• Advanced supervision fuctions - Eg. network test, tone test, status reports, uptime, button status
• SIP support - RFC 3261 (SIP base standard) RFC 3515 (SIP refer) RFC 2976 (SIP info), SIP using TLS, RFC 5630 SIPS URI scheme
• DTMF support - RFC 2833, RFC 2976 (SIP info)
• Max length extension numbers - 20 digits

Environment and Compliances

• IP rating - IP-66, tested according to EN 60529 (applies when mounted in TA-1 back-box)
• IK rating - IK10, tested according to EN 62262
• Operating temperature range - -40° to 70°C
• Storage temperature range - -40° to 70°C
• Relative humidity - <95% not condensing
• Corrosion - Salty mist, tested according to EN60945
• Vibration - Tested according to EN60945
• UV-resistant - Yes
• EMC - CE and FCC Part 15 EN 50121-3-2 Railway application EN 50121-4 Railway application UN Regulation 10, revision 4 + Corr.1 + Amend.1
• Compliances - IEC/EN 60945 Marine Equipment IEC/EN61000-6-1 and IEC/EN61000-6-3 (light industry) IEC/EN 50155 Railway Application* IEC/EN 50486 Equipment for use in audio video door-entry systems * With additional conformal coating Reuqires use of EN 50155 approved PoE switch
• Certifications - UL 60950-1, cUL 60950-1, CB to IEC 60950-1

Others Specifications

• IP address information - Speaks IP address after system boot
• Button lifetime - > 1000 000 cycles
• Country of manufacture - Poland
