DWC-LPR650UW Digital Watchdog 6-50mm Varifocal 30FPS @ 1080p Outdoor IR Day/Night LPR HD-TVI/HD-CVI/AHD/Analog Security Camera 12VDC/24VAC - White

STAR-LIGHT 2.1MP Universal HD over COAX cameras deliver crystalclear images and support real-time 30fps HD-Analog, HD-TVI, HD-CVI and all analog signals to 960H. The IP66 rated camera is engineered to capture license plates of moving vehicles in extreme light or weather conditions, from ranges of 13 to 100 feet at up to 50mph. STAR-LIGHT Universal HD over COAX cameras are engineered to work with our VMAX A1 Universal HD over COAX DVRs using your existing coax infrastructure.

Specifications


• Image Sensor - 2.1 MP1/3" CMOS
• Active Pixels - 1944(H) x 1092(V)
• Scanning System - Progressive scan
• Frequency - 60Hz/50Hz
• Video Output - HD-Analog, HD-TVI, HD-CVI 2.1MP 1080p CVBS Analog up to 960H
• Synchronization - Internal
• Resolution - 1920x1080 (1080p)
• Minimum Scene Illumination - F1.4 (30IRE): 0 Lux (B/W)
• S/N Ratio - 55dB
• Signal Technology - Universal HD over Coax Technology with HD-Analog, HD-TVI, HD-CVI and all Analog to 960H Signal Support
• Alarm Output - 1 Alarm Output

Lens

• Focal Length - 6~50mm
• Lens Type - Varifocal P-Iris Lens
• Field of View (FoV) - 45.3° ~ 5.7°
• IR Distance - 115ft

Operational

• Capture Image Range - 13'~115'
• Max. Vehicle Speed - 50mph
• Shutter Mode - Auto, Manual, FLC
• Shutter Speed - 1/30-1/30,000
• Backlight - On, Off
• Smart DNR 3D Digital Noise Reduction - Off, Low, Middle, High
• Dynamic Range Compressor (DRC) - Off, Low, Middle, High
• Day and Night - Night
• Mirror/ Flip - Yes
• Auto Gain Control - Max 60dB
• Motion Detection - Yes
• Privacy Zones - 16 Privacy Zones
• Sharpness - 0 ~ 10
• Gamma - 0.45 ~ 0.75
• RS485 / UTP Built-in - PELCO D / PELCO C

Environmental

• Operating Temperature - -20°C ~ 50°C (-4°F ~ 122°F)
• Operating Humidity - than 90% (Non-Condensing)
• IP Rating - IP66 Certified Weather and Tamper Resistant
• Other Certifications - FCC, CE, ROHS

Electrical

• Power Requirements - DC12V/AC24V Dual Voltage
• Power Consumption
  • DC12V (LED ON): 6.12W
  • AC24V (LED ON): 5.7W

Mechanical

• Material - Aluminum Bullet Housing
• Dimensions - 9.4" x 3.81" Inch (264 x 96.7mm)
• Weight - 1.83lbs

DWC-LPR650UW Specifications PDF
