500450-LR Muxlab HDMI LR Extender Kit Plus HDBT UHD-4K

Specifications

• Environment - HDMI 1.3a
• Devices - DVDs, Blu-ray players, projectors, monitors, TVs, PCs, laptops, servers supporting HDMI.
• Transmission - Transparent to the user.
• Bandwidth - 148.5MHz
• Signals - HDMI 1.3a protocol.
• Connectors Cables not included. - One (1) HDMI receptacle. One (1) RJ45S for Cat5e/6 unshielded or shielded twisted pair. One (1) 3.5mm jack for IR Sensor & Emitter (carrier-wave).
• Max. Distance* *Based on a maximum length of 6.6 ft (2m) of HDMI cable per end. - 480i/p: Cat 5e/6: 500 ft (150 m) 720p, 1080i: Cat 5e/6: 500 ft (150 m) 1080p 8-Bit: Cat 5e/6: 500 ft (150 m) Note: When installed in an electrically noisy environment, an STP cable must be used. Also, crossconnection reduces the effective distance depending on the grade of twisted cable used.
• RJ45 Pin Configuration Reverse Polarity Sensitive Use EIA/TIA 568 A or B, straight through wiring. - RJ45 Pin 1 (R) Pin 2 (T) Pin 3 (R) Pin 6 (T) Pin 4 (R) Pin 5 (T) Pin 7 (R) Pin 8 (T)
• Cable - One (1) Category 5e or better twisted pair cables required.
• Power Supply - Two (2) 110-240V/5VDC power supplies with interchangeable blades.
• Power Consumption - Transmitter: 4 Watt Receiver: 6 Watt
• Temperature - Operating: 0º to 40º C. Storage:-20º to 85º C. Humidity: up to 95% non-condensing.
• Enclosure - Aluminum
• Dimensions - 4.50" x 3.00" x 1.25" (11.4 x 7.6 x 3.2 cm)
• Weight - 2.6 lb (1.2 kg)
• Compliance - Regulatory: FCC, CE, RoHS Flammability: 94V0
• Warranty - 2 years
• Order Information - 500450-LR HDMI Extender Kit Long-Reach, HDBT, UHD-4K (UPC: 627699014509)
