QSW-M7308R-4X-US QNAP Half-Rackmount Switch

SKU: QSW-M7308R-4X-US

Brand: QNAP

Includes four 100GbE QSFP28 and eight 25GbE SFP28 fiber ports to offer a backbone switching capacity of 1200Gbps for uplinking server rooms
The user-friendly QNAP Switch System (QSS) centralizes and simplifies central network management with an overview dashboard, port management, and settings guide
Provides Layer 2 management features (such as LACP, VLAN, ACL and LLDP) for efficiently controlling network bandwidth and enhancing security
One of the few compact 100GbE switches on market, the QSW-M7308R-4X, can be installed in a 1U rack space with another half-width rackmount switch for efficient physical space utilization
Supports FEC (Forward Error Correction) and IEEE-802.3ap Auto-Negotiation for high compatibility to connect to QNAP 25GbE NAS or NAS installing 100G network cards for high-performance, low-latency computing
QSS can be updated with just one click, helping IT staff ensure their network security

MPN: QSW-M7308R-4X-US
UPC: 885022026647

MSRP Price: $999.00

Online Price: $999.00

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

Specifications

Management Type - Web Managed
Number of Ports - 12
100GbE QSFP28 - 4
25GbE SFP28 - 8
Management Port - 1 x 1GbE RJ45
Power Supply Description - Internal Power supply unit
Max. Power Consumption - 55.153W
Input Power Type - AC
Input Voltage Range - 100-240VAC, 50/60Hz
MAC Address Table - 32K
Total Non-Blocking Throughput - 600Gbps
Switching Capacity - 1200Gbps
Management Interface - Web
Console - RJ45
Fan - PWM VAPO Bearing fan x 2
Supported Standards
- IEEE 802.3 Ethernet
- IEEE 802.3u 100BASE-T
- IEEE 802.3ab 1000BASE-T
- IEEE 802.3z 1000BASE-SX/LX
- IEEE 802.3ae 10G Fiber
- IEEE 802.3x Full-Duplex Flow Control
- IEEE 802.1Q VLAN Tagging
- IEEE 802.1w RSTP
- IEEE 802.3ad LACP
- IEEE 802.1AB LLDP
- IEEE 802.1p Class of Service
Form Factor - Half-width rackmount
LED Indicators - Per Port: Speed/Link/Activity Per System: Power/Status/Locater
Buttons - Reset button
Dimensions (HxWxD) - 43.3 x 207 x 248.8 mm
Weight (Net) - 3.92 lbs
Weight (Gross) - 5.8 lbs
Operating Temperature - 0˚C to 40°C (32°F to 104°F)
Relative Humidity - 5~95% Non-condensing
Certifications - CE, FCC, VCCI, BSMI
Electromagnetic Compliance - CLASS A
Jumbo Frames - 9K
Warranty - 2 Years
