SD9365-EHL Vivotek 4.7-94mm 20x Optical Zoom 60FPS @ 1080p Outdoor IR Day/Night WDR PTZ IP Security Camera 24VDC/PoE

Specifications

System Information

• CPU - Multimedia SoC (System-on-Chip)
• Flash - 128MB
• RAM - 512MB

Camera Features

• Image Sensor - 1/3" Progressive CMOS
• Max. Resolution - 1920x1080
• Lens Type - 20x Optical Zoom, Auto Focus
• Focal Length - f = 4.7 ~ 94 mm (20x zoom)
• Aperture - F1.6 ~ F3.5
• Iris type - DC-Iris
• Field of View
  • 3° ~ 55° (Horizontal)
  • 2° ~ 33° (Vertical)
  • 3° ~ 63° (Diagonal)
• Shutter Time - 1/8 sec to 1/30,000 sec
• WDR Technology - WDR Pro
• Day/Night - Yes
• Removable IR-cut filter - Yes
• IR Illuminators - Built-in IR Illuminators up to 150 meters with Smart IR II, IR LED*2
• Minimum Illumination
  • 0.26 Lux @ F1.6 (Color)
  • 0.01 Lux @ F1.6 (B/W)
  • 0 Lux with IR illumination on
• Pan Speed - 0.1° ~ 300° / sec
• Pan Range - 360° endless
• Tilt Speed - 0.1° ~ 300° / sec
• Tilt Range - 220° ( -110° ~ +110° )
• Preset Locations
  256 preset locations
  • 128 presets per tour
• Pan/Tilt/Zoom Functionalities - 128x digital zoom (4x on IE plug-in, 32x built-in), Auto pan mode, Auto patrol mode
• On-board Storage - Slot type: Micro SD/SDHC/SDXC card slot Seamless Recording

Video

• Compression - H265, H264, MJPEG
• Maximum Frame Rate
  • H.265 & H.264: 60 fps @ 1920x1080
  • MJPEG: 30 fps @ 1920x1080
• Maximum Streams - 4 simultaneous streams
• S/N Ratio - 53 dB
• Dynamic Range - 110 dB
• Video Streaming - Adjustable resolution, quality and bitrate Smart Stream II
• Image Settings - Adjustable image size, quality and bit rate; Time stamp, text overlay, flip & mirror; Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks (Up to 24); Scheduled profile settings, defog, 3DNR, EIS, HLC

Audio

• Audio Capability - Two-way Audio
• Compression - G.711, G.726
• Interface
  • External microphone input
  • External line output

Network

• Users - Live viewing for up to 10 clients
• Protocols - IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS, NTCIP
• Interface
  • 10 Base-T/100 Base-TX/1000 Base-T Ethernet (RJ-45)
  • It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
• ONVIF - Supported, specification available at www.onvif.org

Intelligent Video

• Video Motion Detection - Five-window video motion detection
• Auto-Tracking - Auto-tracking on moving object

Alarm and Event

• Alarm Triggers - Motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection, audio detection
• Alarm Events - Event notification using digital output, HTTP, SMTP, FTP, NAS server and Micro SD card File upload via HTTP, SMTP, FTP, NAS server and Micro SD card

General

• Connectors
  • RJ-45 cable connector for Network 10/100 Mbps PoE connection*1
  • Audio input*1
  • Audio output*1
  • AC/DC 24V power input*1
  • Digital input*4
  • Digital output*2
  • RS-485 for PTZ control (PelcoD protocol, Baud rate 2400)*1
• LED Indicator - System power and status indicator
• Power Input - PoH/PoE (95W),AC/DC 24V
• Power Consumption
  • PoH/PoE (95W):Max. 70 W (Heater on),Max. 39 W (Heater off)
  • AC/DC 24V:Max. 96 W (Heater on),Max. 45 W (Heater off)
• Dimensions - 236.45 x 364.2 mm
• Weight
  • 7.1 kg (with bracket)
  • 5.7 kg (without bracket)
• Casing - IP66, IK10, NEMA 4X
• Safety Certifications - CE, FCC Class A, VCCI, C-tick, NEMA 4X, UL
• Operating Temperature
  • Starting Temperature: -40°C ~ 55°C (-40°F ~ 131°F)
  • Working Temperature: -40°C ~ 55°C (-40°F ~ 131°F)
• Humidity - 90%
• Warranty - 36 Months

System Requirements

• Operating System - Microsoft Windows 8/7
• Web Browser
  • Mozilla Firefox 7~43 (streaming only)
  • Internet Explorer 10/11
• Other Players
  • VLC: 1.1.11 or above
  • Quicktime: 7 or above

Included Accessories

• CD - User's manual, quick installation guide, Shepherd, VAST
• Others - Wall mount bracket*, I/O cable*, screws, waterproof connectors, terminal blocks, quick installation guide, warranty card, alignment sticker, ground wire, T25 stardriver, software CD, desiccant bags*: Standard package for SD9365-EHL(with Bracket, IO Cable).
