IPC2125SR5-ADF28KM-G Uniview Prime I Series 2.8mm 30FPS @ 5MP Outdoor IR Day/Night WDR Bullet IP Security Camera 12VDC/PoE

SKU: IPC2125SR5-ADF28KM-G

Brand: Uniview

High quality image with 5MP, 1/2.7"CMOS sensor
30/25fps @ 5MP (2880x1620); 30/25fps @ 4MP (2560x1440); 30/25fps @ 3MP (2304x1296); 30/25fps @ 2MP (1920x1080)
Ultra 265, H.265, H.264, MJPEG
Easystar technology ensures high image quality in low illumination environment
120dB true WDR technology enables clear image in strong light scene
Support 9:16 Corridor Mode
Built-in Mic
Smart IR, up to 164ft (50m) IR distance
Complies with Section 889 of the NDAA

MPN: IPC2125SR5-ADF28KM-G
Availability: In Stock
Ordering Notes: Service Professionals Only

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

Specifications

Camera

Sensor - 1/2.7", 5.0 megapixel, progressive scan, CMOS
Lens - 2.8mm@F1.6
DORI Distance - Lens (mm) - 2.8, Detect (m) - 63.0, Observe (m) - 25.2, Recognize (m) - 18.0, Identify (m) - 6.3
Angle of View (H) - 112.9°
Angle of View (V) - 59.1°
Angle of View (O) - 121.2°
Adjustment angle - Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotate: 0° ~ 360°
Shutter - Auto/Manual, 1 ~ 1/100000s
Minimum Illumination - Support Easystar: Colour: 0.003Lux ( F1.6, AGC ON), 0Lux with IR on
Day/Night - IR-cut filter with auto switch (ICR)
Digital noise reduction - 2D/3D DNR
S/N - >56dB
IR Range - Up to 164ft (50m) IR range
Wavelength - 850nm
IR On/Off Control - Auto/Manual
Defog - Digital Defog
WDR - 120dB

Video

Video Compression - Ultra 265, H.265, H.264, MJPEG
H.264 code profile - Baseline profile, Main profile, High profile
Main Stream - Max 30fps @ 5MP (2880 x 1620), Max 30fps @ 4MP (2560 x 1440), Max 30fps @ 3MP (2304 x 1296), Max 30fps @ 1080P (1920x1080)
Sub Stream - Max 30fps @ 720P (1280 x 720), Max 30fps @ D1 (720 x 576), Max 30fps @ 640 x 360, Max 30fps @ 2CIF (704 x 288), Max 30fps @ CIF (352 x 288)
Video Bit Rate - 128 Kbps~16 Mbps
9:16 Corridor Mode - Supported
OSD - Up to 4 OSDs
Privacy Mask - Up to 4 areas
ROI - Up to 8 areas
Motion Detection - Up to 4 areas


Audio

Storage

Smart

Behavior Detection - (Cross line, intrusion)based on human body detection, motion detection, tampering alarm, audio detection
General Function - Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, HTTP authentication

Network

Protocols - IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS, 802.1x, SNMP
Compatible Integration - ONVIF (Profile S, Profile G, Profile T), API
Client - EZStation, EZView, EZLive
Web Browser - Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below, Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+

Interface

Certifications

General

Power - DC 12V±25%, PoE (IEEE 802.3af), Power consumption: Max 6.0W
Dimensions (L x W x H) - 7.5"x2.9"x2.8" (190x73x71mm)
Net Weight - 0.99lb (0.45kg)
Material - Metal
Working Environment - -22°F ~ 140°F (-30°C ~ 60°C), Humidity: ≤95% RH (non-condensing)
Strorage Environment - -22°F ~ 140°F (-30°C ~ 60°C), Humidity: ≤95% RH (non-condensing)
Surge Protection - 4KV
Ingress Protection - IP67
Reset Button - N/A
