TVIPTZ2-23X-IR Rainvision 4-92mm 23x Optical Zoom 30FPS @ 1080p Outdoor IR Day/Night PTZ HD-TV/HD-CVI/AHD/Analog Security Camera 12VDC

Specifications

Camera

• Imaging Device - 1/2.8" Progressive Scan CMOS
• Min. Illumination - Color: 0.05 Lux @ f/1.4, AGC ON, B/W: 0.005 Lux @ f/1.4, AGC ON, 0 Lux with IR
• Shutter Speed - 4-92mm 23x Optical Zoom
• Digital Zoom - 16x
• Angle of View - 49° to 2.2° ( Wide to Tele )
• Day & Night - IR Cut Filter
• IR Range - 330'
• DNR - 3D DNR
• DWDR - Supported
• Pan and Tilt - Pan: 360° Endless, Tilt: -15°~90° ( Auto Flip )
• Speed - Pan Manual Speed: 0.1° to 80°/s, Pan Preset Speed: 80°/s, Tilt Manual Speed: 0.1° to 80°/s, Tilt Preset Speed: 80°/s
• Number of Presets - 256
• Patrols - 8 Patrols, Up to 32 Presets Per Patrol
• Scheduled Task - Preset / Patrol / Pattern / Pan scan / Tilt scan / Panorama scan


• Max. Resolution - 2MP (1920 x 1080)
• Frame Rate - 30FPS @ 1920 x 1080
• BLC - Support
• AGC - Auto / Manual

Input / Output

• Video Output - Switchable HD-TVI / HD-CVI / AHD / CVBS Output
• RS-485 Interface - Half-duplex Mode Self-adaptive Rainvision, Pelco-P, Pelco-D protocol
• UTC Function - Up The Coax Control

General

• Operating Conditions - -22 °F ~ 149 °F
• Humidity - Humidity 90% or less (non-condensing)
• Power Requirement - 12VDC
• Power Consumption - Max. 18W
• Ingress Protection - IP66, TVS 4,000 V Lightning Protection, Surge Protection and Voltage Transient Protection
• Communication - Up the Coax and RS-485
• Dimensions - 6.52" x 11.61"
• Weight - 4.41 lb
• Warranty - 2 Years
• Package Contents - Camera, Manual, 12V DC Power Adapter

TVIPTZ2-23X-IR Specifications PDF
