NCT-5ML-OV2 Nuvico Xcel Series 2.8mm 20FPS @ 5MP Indoor/Outdoor IR Day/Night DWDR Vandal Dome IP Security Camera 12VDC/PoE

Specifications

Video

• Image Sensor - 1/2.7" CMOS
• Image Size - 5MP (2592 x 1944)
• Lens - 2.8mm
• Field of View - Horizontal: 93.4°, Vertical: 77°, Diagonal: 106°
• Electronic Shutter - 1/25s ~ 1/100,000s
• IR Distance - Up to 100ft
• Frame Rate - 20fps @ 5MP
• Min. Illumination - 0.0085 lux @ F1.2, AGC On; 0 lux with IR On
• Angle Adjustment - Pan: 0°~355°, Tilt: 0°~67°, Rotation: 0°~355°


• Video Compression - H.265 / H.264
• Resolution - 5MP / 4MP / 1080p / 720p / D1 / CIF / 480 x 240
• Main Stream - 60Hz: Up to 20fps @ 5MP, 30fps @ 4MP / 1080p / 720p, 50Hz: Up to 20fps @ 5MP, 25fps @ 4MP / 1080p / 720p
• Sub Stream - 60Hz: Up to 15fps @ 720p, 30fps @ D1 / CIF, 50Hz: Up to 12fps @ 720p, 25fps @ D1/CIF
• Third Stream - 60Hz: 30fps @ D1 / CIF / 480 x 240, 50Hz: 25fps @ D1 / CIF / 480 x 240
• Bit Rate - 64 Kbps ~ 5 Mbps
• Encode Mode - VBR / CBR
• Image Settings - ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, NR, etc. Adjustable Through Client Software or Web Browser

Functions

• Remote Monitoring - Web Browsing, CMS Remote Control
• Online Connection - Simultaneous Monitoring for Up to 4 Users, Supports Multi-stream Real Time Transmission
• Network Protocol - UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, 802.1x, UPnP, HTTP, HTTPs, QoS
• Interface Protocol - ONVIF, Nuvico Xcel
• Storage - Network Remote Storage
• Smart Alarm - Motion Alarm
• Intelligent Analytics - Scene Change, Video Blur Detection, Video Color Cast Detection, Line Crossing Detection, Intrusion Detection
• Day & Night - ICR
• WDR - Digital WDR
• DNR - 3D DNR
• BLC - Yes
• Defogging - Yes
• HLC - Yes

General

• Connectors - RJ45, 12VDC Power Input
• Power Requirement - 12VDC / PoE
• Power Consumption - < 6W
• Protection - IP67, IK10
• Working Environment - -22°F ~ 140°F
• Relative Humidity - Less than 95% Non-condensing
• Weight - 1.32 lbs
• Dimensions - Ф4.69" x 3.46"
• Warranty - 3 Years
• Package Contents - Camera, Manual, Template, Installation Accessories

NCT-5ML-OV2 Specifications PDF
