[DISCONTINUED] TN-P802-8P Nuvico Xcel Series 8 Channel NVR 50Mbps Max Throughput w/ Built-in 8 Port PoE- 2TB

The Nuvico Xcel TN-P series is available in a 8 or 32 channel model supporting IP video. The TN-P series utilizes the most advanced SOC techniques along with H.265 compression format to deliver real time recording, while maintaining quality and maximizing video storage and fluidity. Based on the Nuvico Xcel software platform, the TN-P series features a mouse driven, clean GUI for easy local control, and is compatible with the Xcel CMS, Web CMS, and mobile apps.

Specifications

System

• Compression - Standard H.265
• OS - Embedded Linux

Video

• Input - 8 Channel IP
• Network Access Bandwidth - 50Mbps
• Network Access Format - 25/30fps @ 8MP, 5MP, 4MP, 3MP, 1080p, 960p, 720p
• Output - HDMI x 1 : 4K x 2K, 1920 x 1080, 1280 x 1024, VGA x 1 : 1920 x 1080, 1280 x 1024

Audio

• Network Input - 8 Channel Audio Input
• Two-way audio - RCA x 1
• Output - RCA x 1

Record

• Record Stream - Dual Stream Recording
• Resolution - 8MP, 5MP, 4MP, 3MP, 1080p, 960p, 720p
• Mode - Manual, Timer, Motion, Sensor

Playback

• Playback - Max 8 Channels
• Search - Time slice / Time / Event / Tag Search
• Smart Search - Highlighted color to display the camera record in a certain period of time, different colors refers to different record events
• Function - Play, Pause, FF, FB, Digital Zoom, etc.

Network

• Interface - RJ45 10/100Mbps x 1
• PoE Port - RJ45 x 8
• Protocol - TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
• Web Client - Multiple Users Online

Alarm

• Mode - Manual, Sensor, Motion, Exception
• Input - 8 Channel IP Alarm Input
• Output - No
• Triggering - Record, Snap, Preset, E-mail, etc.

Mobile Device

• OS - iOS, Android

Storage

• HDD - SATA x 2, Max 10TB per HDD

Back Up

• Local Backup - U Disk, USB Mobile HDD
• Network Backup - Yes

Port

• USB - USB 2.0 x 2 ( One in the front panel and the other in the rear panel )
• Remote Controller - Optional

General

• Power Supply - 48VDC
• Power Consumption - ≤ 5W ( without HDD )
• Working Environment - 14°F ~ 122°F
• Relative Humidity - 10% ~ 90% humidity
• Weight - 5.84 lbs (without HDD)
• Form Factor - 1U Rackmount Case
• Dimensions - 14.96" W x 10.55" D x 2.05" H
• Package Contents - Recorder, IR Remote, USB Mouse, Power Cord, Rackmount Ears, Installation CD, Manual

TN-P802-8P Specifications PDF
