NTCT-3M-IRPTZ20 Nuvico Xcel Series 5.5~110mm 20x Optical Zoom 30FPS @ 3MP Outdoor IR Day/Night WDR PTZ IP/HD-TVI/AHD Security Camera 24VAC/24VDC

Specifications

Video

• Image Sensor - 1/2.8" CMOS
• Image Size - IP: 3MP (2688 x 1520), HD-TVI / AHD: 2MP (1920 x 1080)
• Lens - 5.5~110mm, 20x Optical Zoom
• IR Distance - Up to 300 ft.
• IR Control - Brightness and Angle of the IR LEDs to be Smartly Adjusted According to the Scenes
• Frame Rate - IP: 30fps @ 3MP, HD-TVI/AHD: 30fps @ 2MP


• Video Compression - H.265 / H.264 / MJPEG
• Main Stream - 2048 x 1536, 1920 x 1080, 1280 x 720
• Sub Stream - 704 x 576, 352 x 288
• Third Stream - 704 x 576, 480 x 240, 352 x 288
• Audio Compression - G711A / U

Functions

• Network Protocol - TCP/IP, UDP, DHCP, UPnP, DDNS, NTP, RTSP, SMTP, FTP, PPPoE, IPv4
• Storage - Network Remote Storage, Micro SD Memory Slot
• Preview Video Channels - Up to 10 Channels
• Pan Range - 360° Endless Rotation
• Pan Speed - Manual Control Speed: .1°~120°/s Preset Speed: 240°/s
• Tilt Range - 0~90°
• Tilt Speed - Manual Control Speed: .1°~90°/s, Preset Speed: 200°/s
• Zoom - Yes
• Preset - 255 Presets
• Cruise - 8 Cruises, 16 Presets Each
• Scan - 2 Scans
• Track - 4 Tracks, 3 Min. Recording Each
• Time Task - Yes
• Home Position - Yes
• Power Off Memory - Yes
• Language - English / Chinese

System Integration

• Alarm Input - 4 Channels ( 5~12V DC）
• Alarm Output - 1 Channel, Alarm trigger (Preset, Snap, FTP Upload and Email Trigger）
• API - API, SDK, ONVIF, Nuvico Xcel
• Web Client - Web 4.0

General

• Connectors - RJ45, RS485, CVBS BNC, 3.5mm Mic Input, 3.5mm Audio Output, 4 x Digital Input, 1 x Digital Output, 24V Power Input
• Power Requirement - 24VAC/24VDC Note: Please use included transformer for power.
• Power Consumption - 60W
• Protection - IP66, IK10, TVS6000V Lightning Protection, Surge Protection
• Working Environment - -4°F ~ 122°F
• Relative Humidity - Less than 90%
• Weight - 15.43 lbs
• Dimensions - Ф8.23" x 12.48"
• Warranty - 1 Year
• Package Contents - Camera, Transformer, Installation CD, Manual, Template, Wall Mount and Mounting Screws
