IPC6652EL-X33-VF Uniview Pro Series 4.5~148.5mm Motorized 60FPS @ 1080p LightHunter Outdoor IR Day/Night WDR PTZ IP Security Camera 24VDC/24VAC/PoE

SKU: IPC6652EL-X33-VF

Brand: Uniview

High quality image with 2MP, 1/2.8" CMOS sensor
60fps @ 1920x1080 in the main stream
Ultra 265, H.265, H.264, MJPEG
Five streams
33X optical zoom
LightHunter technology ensures ultra-high image quality in low illumination environment
Vari-focal laser: 500m (1640ft) distance, proportional to optical zoom of camera module
AC 24V ±25%, DC 24V±25%, POE(PSE Required)
Complies with Section 889 of the NDAA

MPN: IPC6652EL-X33-VF
Availability: Special Order
Ordering Notes: Service Professionals Only

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

Specifications

Camera

Lens

DORI

DORI Distance - Lens (mm) - 4.5, 148.5, Detect (m) - 239.3ft (72.9), 7178.3ft (2187.9), Observe (m) - 95.7ft (29.2), 2871.3ft (875.2), Recognize (m) - 47.9ft (14.6), 1435.7ft (437.6), Identify (m) - 23.9ft (7.3), 717.8ft (218.8)

Illuminator

Video

Video Compression - Ultra 265, H.265, H.264, MJPEG
Frame Rate
- Main Stream - 60fps @ 2MP (1920 x 1080)
- Sub Stream - 60fps @ 2MP (1920 x 1080)
- Third Stream - 60fps @ D1 (720 x 576)
- Fourth Stream - 60fps @ D1 (720 x 576)
- Fifth Stream - 60fps @ D1 (720 x 576)
Video Bit Rate - 128 Kbps~16 Mbps
H.264 Type - Baseline Profile/Main Profile/High Profile
H.265 Type - Main Profile
U-code - Support
ROI - Up to 8 areas
Video stream - Five streams
OSD - Up to 8 OSDs
Privacy Mask - Up to 24 blacks (Up to 4 blacks in the same picture)


White Balance - Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction - 2D/3D DNR
Flip - Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90° Anti-clockwise
HLC - Support
BLC - Support
Defog - Digital Defog

Events

Basic Detection - Motion detection, Audio detection, Tampering alarm
Auto-tracking - Support later
General Function - Watermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication

Audio

Storage

Network

Protocols - IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS
Compatible Integration - ONVIF (Profile S, Profile G, Profile T), API, SDK
User/Host - Up to 32 users. 2 user levels: administrator and common user
Security - Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client - EZStation, EZView, EZLive
Web Browser - Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below

Pan & Tilt

Tilt Speed

Interface

Certifications

EMC - FCC CFR 47 Part 15, EN 55032:2015, EN 55024:2010, EN 61000-3-2:2014, EN 61000-3-3-2013
Environment - CE-ROHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); REACH (Regulation (EC) No 1907/2006)
Protection - Ingression protection: IP66 (IEC 60529-2013)

General

Power - AC 24V±25%, DC 24V±25%, PoE (PSE Required), Power consumption: Max 53W
Power Interface - Wires with cold-pressed terminal
Dimensions (Ø x H) - Ø8.9" x 15.2" (Ø227 x 385mm)
Weight - 12.54lb (5.7kg)
Working Environment - -40°F ~ 158°F (-40°C ~ 70°C), Humidity: ≤95% RH (non-condensing)
Strorage Environment - -40°F ~ 158°F (-40°C ~ 70°C), Humidity: ≤95% RH (non-condensing)
Surge Protection - 6KV
Ingress Protection - IP66
Reset Button - Support
