IPC6312LR-AX4W-VG Uniview Easy Series 2.8~12mm 4x Optical Zoom 30FPS @ 1080p LightHunter Outdoor IR Day/Night WDR PTZ IP Security Camera Built-in WiFi 12VDC

Specifications

Camera

• Sensor - 1/2.7" progressive scan, 2.0 megapixel, CMOS
• Min. Illumination - Colour: 0.002Lux (F1.6, AGC ON), 0Lux with IR on
• Day/Night - IR-cut filter with auto switch (ICR)
• Shutter - Auto/Manual, shutter time: 1 s ~ 1/100000 s
• WDR - 120dB
• S/N - >52dB

Lens

• Lens type - 2.8~12mm, AF automatic focusing and motorized zoom lens
• Optical Zoom - 4
• Iris - Fixed; F1.6
• Field of View (H) - 105.2° ~ 29.32°
• Field of View (V) - 52.6° ~ 16.38°
• Field of View (D) - 108.7° ~ 33.3°

DORI

• DORI Distance - Lens (mm): 2.8mm - 12mm, Detect (m): 43.4 (142.4ft) - 186.2 (610.9ft), Observe (m): 17.4 (57.1ft) - 74.5 (244.4ft), Recognize (m) : 8.7 (28.5ft) - 37.2 (122.1ft), Identify (m) : 4.3 (14.1ft) - 18.6 (61.0ft)

Illuminator

• IR Range - Up to 164ft (50m)
• Wavelength - 850nm
• IR On/Off Control - Auto/Manual

Video

• Video Compression - Ultra 265, H.265, H.264, MJPEG
• Frame Rate
  • Main Stream - 30fps @ 2MP (1920 x 1080); 30fps @ 720P (1280 x 720)
  • Sub Stream - 30fps @ 720P (1280 x 720); 30fps @ D1 (720 x 576), 30fps 640 x 360, 30fps @ 2CIF(704 x 288), 30fps @ CIF(352 x 288)
  • Third Stream - 30fps @ D1 (720 x 576), 30fps (640 x 360), 30fps @ 2CIF(704 x 288), 30fps @ CIF(352 x 288)
• Video Bit Rate - 128 Kbps ~ 16 Mbps
• ROI - Support
• Video Stream - Triple streams
• OSD - Up to 8 OSDs
• Privacy Mask - Up to 4 areas


• White Balance - Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
• Digital Noise Reduction - 2D/3D DNR
• Smart IR - Support
• Flip - Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise
• HLC - Support
• BLC - Support
• Defog - Digital Defog

Intelligent

• Smart Intrusion Prevention - Support false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection
• People Counting - Support people flow counting and crowd density monitoring

Events

• Basic Detection - Motion detection, Audio detection, Tampering Alarm
• Auto Tracking - Support
• General Function - Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication

Audio

• Audio Compression - G.711U,G.711Ab
• Two-way Audio - Support
• Suppression - Support
• Sampling Rate - 8 kHz

Storage

• Edge Storage - Micro SD, up to 256 GB
• Network Storage - ANR,NAS(NFS)

Network

• Protocols - IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP , PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP , 802.1x , SNMP, SSL
• Compatible Integration - ONVIF (Profile S, Profile G, Profile T), API
• Client - EZStation, EZLive, EZView
• Web Browser - Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above

Wi-Fi

• Wireless Standards - IEEE802.11b/g/n
• Frequency Range - 2.4 GHz ~ 2.4835 GHz
• Channel Bandwidth - 20 MHz Support
• Modulation Mode - 802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM/HT
• Security - 64/128-bit WEP, WPA-PSK/WPA2-PSK
• Transmit Power
  • 802.11b: 17±1.5dBm @11Mbps
  • 802.11g: 14±1.5dBm @ 54Mbps
  • 802.11n: 12.5±1.5dBm @150Mbps
• Receive Sensitivity
  • 802.11b: -90dBm @11Mbps (Typical)
  • 802.11g: -75dBm @54Mbps (Typical)
  • 802.11n: -74dBm @150Mbps (Typical)
• Transmission Rate
  • 802.11b: 11Mbps
  • 802.11g: 54Mbps
  • 802.11n: up to 150Mbps

Pan & Tilt

• Pan Range - 0° ~ 345°
• Pan Speed - 0.1°/s ~ 50°/s, Preset speed: 50°/s
• Tilt Range - -10° ~ 110°
• Tilt Speed - 0.1°/s ~ 40°/s, Preset speed: 40°/s
• Number of Presets - 256
• Preset Patrol - 16 patrols, up to 64 presets for each patrol
• Patrol Stay Time - 120s~1800s
• Home Position - Support

Interface

• Built-in Mic - Support
• Built-in Speaker - Support
• Network - 1 * RJ45 10M/100M Base-TX Ethernet

Certification

• EMC - CE-EMC (EN 55032:2015+A11:2020; EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55035:2017+A11:2020 ) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014
• RF - FCC ID (FCC CFR 47 part15 C) CE RED (EN301 489-1 V2.2.3; EN 301 489-17 V3.2.4; EN 300 328 V2.2.2; EN IEC 62311:2020
• Safety - CE LVD (EN 62368-1:2014+A11:2017), CB (IEC 62368-1:2014), UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
• Environment - CE-ROHS (2011/65/EU;(EU)2015/863)
• Protection - IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013

General

• Power - DC12V(±25%), Power consumption: MAX 12W
• Power Interface - Ø 5.5mm coaxial power plug
• Dimensions (Ø x H) - Φ5.2"x 9.8" (Φ133mm x 248mm)
• Weight - 1.90lb (0.86 kg)
• Working Environment - -4°F to 140°F (-20°C ~ 60°C), Humidity:≤95% RH(non-condensing)
• Storage Environment - -40°F to 158°F (-40°C ~ 70°C), Humidity:≤95% RH(non-condensing)
• Surge Protection - 2KV
• Reset Button - Support
