[DISCONTINUED] UVS-ADR1300 Geovision USAVision 2.8mm 30FPS @ 1280 x 960 Outdoor IR Day/Night WDR Dome IP Security Camera 12VDC/POE

Specifications

Camera

• Image Sensor - 1/3" progressive scan low lux CMOS
• Picture Elements - 1280 (H) x 960 (V)
• Minimum Illumination
  • Color - 0.02 Lux
  • B/W - 0.02 Lux
  • IR ON - 0 Lux
• Shutter Speed - Auto / Manual (1/6 ~ 1/8000 sec)
• White Balance - Auto / Manual
• Gain Control - Auto / Manual
• S/N Ratio - 50 dB
• WDR - Yes
• Dynamic Range - 72 dB

Optical Lens

• Megapixel - Yes
• Day / Night - Yes (with removable IR-cut filter)
• Lens Type - Fixed
• Focal Length - 2.8 mm
• Maximum Aperture - F/2.0
• Mount - M12
• Horizontal FOV - 96.5°

Operation

• Focus - Fixed
• Zoom - Fixed
• Iris - Fixed
• IR LED Quantity - 30 IR LED
• Max. IR Distance - 30 m (98.4 ft)

Video

• Video Compression - H.264, MJPEG
• Video Streaming - Triple streams from H.264 or MJPEG
• Video Resolution
  • Main Stream - 1280 x 960, 1280 x 720 (Default), 720 x 576
  • Sub Stream - 1280 x 960, 1280 x 720, 720 x 576 (Default), 352 x 288, 704 x 288
  • Third Stream (Closed by Default) - 720 x 576, 352 x 288, 704 x 288
• Frame Rate - 30 fps at 1280 x 960 (60 / 50 Hz) * The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes)

Network

• Interface - 10/100 Ethernet
• Protocol - DHCP, DNS, FTP, HTTP, ICMP, IGMP , IPv4, IPv6, NTP, ONVIF (Profile S), QoS, RTP, RTSP, TCP, UDP

Mechanical

• Temperature Detector - No
• Connectors
  • Power - DC Jack, PoE
  • Ethernet - RJ-45 connector
  • Local Storage - Micro SD card slot (SD/SDHC/SDXC/UHS‐I, Class 10) *UHS‐II card type is not supported
• Camera Angle Adjustment
  • Pan - 3° ~ 360°
  • Tile - 0° ~ 68°
  • Pan - 3° ~360°

General

• Operating Temperature - -35°C ~ 60°C (-31°F ~ 140°F)
• Humidity - 0% ~ 95% (non-condensing)
• Dimensions - 157.3 x 62.4 x 63 mm (6.2" x 2.5" x 2.5")
• Weight - 0.45 kg (0.99 lb)
• Power Source - 12 VDC / PoE (IEEE802.3af)
• Max. Power Consumption - 5.5 W
• Ingress Protection - IP66
• Regulatory - FCC, IC, CE, WEEE, RoHS compliant

Web Interface

• Installation Management - Web-based configuration
• Maintenance - Firmware upgrade through Web Browser or Utility
• Access from Web Browser - Live View, Video Recording, Change Video Quality, Bandwidth Control, Image Snapshot, Defog, Text Overlay, Image Masking
• Language - English

Applications

• Software Supported - GV-DVR / NVR (V8.7.1.0), GV-VMS (V15.11.1.0), GV-Control Center (V3.4.0.0), GV-Recording Server (V1.3.0.0), GV-Redundant / Failover Server (V1.1.0.0)
• Live Viewing - Browser (IE, Firefox, Safari)

UVS-ADR1300 Specifications PDF
