IPC8542ER5-DUP Uniview Pro Series Multi-Sensor 4.2mm 30FPS @ 8MP Outdoor IR Day/Night WDR Panoramic IP Security Camera 24VDC/24VAC/PoE

Specifications

Camera

• Sensor - 1/1.8" progressive scan, 2.0 megapixel, CMOS
• Lens - 4x4.2mm lens
• Iris - F1.8
• DORI Distance - Lens (mm) - 4.2, Detect (m) - 50.4 (165.4ft), Observe (m) - 20.2(66.3ft), Recognize (m) - 10.1(33.1ft), Identify (m) - 5.0(16.4ft)
• Angle of View (H) - 180°
• Angle of View (V) - 80°
• Angle of View (O) - 221.4°
• Shutter - Auto/Manual, shutter time: 1 s ~ 1/100000 s
• Adjustment angle - Pan: -90°~90°, Tilt: -45°~60°
• Minimum Illumination - Colour: 0.002 lux (F1.8, AGC ON), 0 Lux with IR
• WDR - 120dB
• Day/Night - IR-cut filter with auto switch (ICR)
• S/N - >52dB
• IR Range - Up to (50m) 164 ft IR range
• Wavelength - 850nm
• IR On/Off Control - Auto/Manual
• Defog - Digital Defog

Video

• Video Compression - Ultra 265, H.265, H.264, MJPEG
• Frame Rate
  • Main Stream - 30fps @ 4096 x 1800
  • Sub Stream - 30fps @ 1920 x 832
  • Third Stream - 30fps @ 1280 x 560
  • Fourth Stream - 30fps @ 1280 x 560
  • Fifth Stream - 30fps @ 1280 x 560
• Video Bit Rate - 128 Kbps~16 Mbps
• ROI - Supported
• Video stream - Five streams
• OSD - Up to 8 OSDs
• Privacy Mask - Up to 8 areas (8 blacks / 8 mosaics)


• White Balance - Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
• Digital noise reduction - 2D/3D DNR
• Smart IR - Support
• Flip - Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise
• HLC - Support
• BLC - Support

Smart

• General Function - Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication

Audio

• Audio Compression - G.711U, G.711A
• Two way audio - Supported
• Suppression - Supported
• Sampling Rate - 8KHZ

Storage

• Edge Storage - Micro SD, up to 256 GB
• Network Storage - ANR, NAS(NFS)

Network

• Protocols - IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP
• Compatible Integration - ONVIF (Profile S, Profile G, Profile T), API
• Client - EZStation, EZView, EZLive
• Web Browser - Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below

Interface

• Audio I/O - Audio cable, 1 Input: impedance 35kΩ; amplitude 2V [p-p], 1 Output: impedance 600Ω; amplitude 2V [p-p]
• Serial Port - 1 RS485
• Alarm I/O - 2/1
• Network - 2*10M/100M/1000M Base-TX Ethernet

Certifications

• Certifications - CE: EN 60950-1, UL: UL60950-1, FCC: FCC Part 15

General

• Power - AC24V±25%/DC24V support 18V-48V, PoE(IEEE 802.3at), Power consumption: Max 24W
• Dimensions (Ø x H) - 10.2"x8.3"x4.5" (259mmx211mmx115mm)
• Net Weight - 5.25lb (2.38kg)
• Working Environment - -40°F ~ 158°F (–40°C ~ +70°C), Humidity: ≤95%RH RH(non-condensing)
• Strorage Environment - -40°F ~ 158°F (–40°C ~ +70°C), Humidity: ≤95%RH RH(non-condensing)
• Surge Protection - 6KV
• Ingress Protection - IP67
