IPC8544EA-KM-I1 Uniview Pro Series Multi-Sensor 2.8mm 30FPS @ 16MP LightHunter Outdoor IR Day/Night WDR Panoramic IP Security Camera 24VDC/24VAC/PoE

Specifications

Camera

• Sensor - 1/1.8" progressive scan, 4.0 megapixel, CMOS
• Min. Illumination - Colour:0.001 lux (F1.6, AGC ON), 0 lux with IR
• Day/Night - IR-cut filter with auto switch (ICR)
• Shutter - Auto/Manual, shutter time: 1 s ~ 1/100000 s
• WDR - Digital WDR
• S/N - >56dB

Lens

• Lens - 4x2.8mm lens
• Iris - F1.6
• Field of View (H) - 180°
• Field of View (V) - 90°
• Field of View (D) - 221.4°

DORI

• DORI Distance
  • Lens (mm) - 2.8, Detect (m) - 63.0(206.7ft), Observe (m) - 25.2(82.7ft), Recognize (m) - 12.6(41.3ft), Identify (m) - 6.3(20.7ft)

Illuminator

• IR Range - Up to 164 ft (50m) IR range
• Wavelength - 850nm
• IR On/Off Control - Auto/Manual

Video

• Video Compression - Ultra 265, H.265, H.264, MJPEG
• Frame Rate
  • Main Stream - 30fps @ (4800x2688)
  • Sub Stream - 30fps @ (2688x1520)
  • Third Stream - 30fps @ (1280x720)
• Video Bit Rate - 128 Kbps~16 Mbps
• ROI - Up to 8 areas
• Video stream - Triple streams
• OSD - Up to 8 OSDs
• Privacy Mask - Up to 8 areas(8 blacks/8 mosaics)


• White Balance - Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
• Digital noise reduction - 2D/3D DNR
• Smart IR - Support
• Flip - Normal/Flip Vertical/Flip Horizontal/180°
• HLC - Support
• BLC - Support
• Defog - Digital Defog

Events

• General Function - Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication

Audio

• Audio Compression - G.711U, G.711A
• Two-way Audio - Supported
• Suppression - Supported
• Sampling Rate - 8KHz

Storage

• Edge Storage - Micro SD, up to 256 GB
• Network Storage - ANR,NAS(NFS)

Network

• Protocols - IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP
• Compatible Integration - ONVIF (Profile S, Profile G, Profile T), API
• Client - EZStation, EZLive, EZView
• Web Browser - Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below

Interface

• Audio I/O - Audio cable, 1 Input: impedance 35kΩ; amplitude 2V [p-p], 1 output: impedance 600Ω; amplitude 2V [p-p]
• Alarm I/O - 2/1
• Network - 10M/100M/1000M Base-TX Ethernet

Certification

• EMC - CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
• Safety - CE LVD (EN 62368-1:2014+A11:2017), CB (IEC 62368-1:2014), UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
• Environment - CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
• Protection - IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013)

General

• Power - AC24V±25%/DC24V±25%, PoE(IEEE 802.3at), Power consumption: Max 34W
• Dimensions (Ø x H) - 10.2"x8.3"x4.5" (258.8mmx211.0mmx115.0mm)
• Weight - 5.01lb (2.271kg)
• Working Environment - -40°F ~ 158°F (–40°C ~ +70°C ), Humidity: ≤95%RH RH(non-condensing)
• Storage Environment - -40°F ~ 158°F (–40°C ~ +70°C), Humidity: ≤95%RH RH(non-condensing)
• surge protection - 6KV

IPC8544EA-KM-I1 Specifications PDF
