IPC568EB-DGK-I0 Uniview Pro Series Motorized 30FPS @ 8MP LightHunter Outdoor IR Day/Night WDR Network Box IP Security Camera 12VDC/24VAC/PoE

SKU: IPC568EB-DGK-I0

Brand: Uniview

High quality image with 8 MP, 1/1.8" CMOS sensor
30 fps @ 3840 Ã— 2160 in the main stream
Ultra 265, H.265, H.264, MJPEG
Smart intrusion prevention, supports false alarm filtering, including cross line, intrusion, enter area, leave area detection
automatic selection of best snapshots, supports face detection masked area
People counting, supports people flow counting and crowd density monitoring, suitable for different statistical scenarios
LightHunter technology ensures ultra-high image quality in low illumination environment
Up to 120 dB optical WDR (Wide Dynamic Range)
Support high-precision motorized lens for accurate zoom & focus
DC 12 V or AC 24 V or PoE (IEEE 802.3af) power supply
Complies with Section 889 of the NDAA

MPN: IPC568EB-DGK-I0

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

Specifications

Camera

Sensor - 1/1.8" CMOS
Min. Illumination - Colour:0.002lux (F1.2, AGC ON), B/W: 0.0002Lux(F1.2, AGC ON)
Day/Night - IR-cut filter with auto switch (ICR)
Shutter - Auto/Manual, 1 to 1/100000 s
WDR - 120 dB
S/N - >56 dB

Lens

Video

Events

Basic Detection< - Motion Detection, Tampering Alarm, Audio Detection, Object Removed, Object Left Behind, Scene Change
General Function - Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication, Alarm Input, Alarm Output

Intelligent

Exception Detection - Object Removed, Object Left Behind, Scene Change
Smart Intrusion Prevention - Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
People Counting - Support People Flow Counting and Crowd Density Monitoring
Traffic Monitoring - Support capturing car license picture when the car passes tripwire, Up to 4 lanes can be set, Two types of application mode avaliable: High/Low pole

Audio

Storage


Network

Protocols - SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible Integration - ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK
User/Host - Up to 32 users. 3 user levels: administrator, common user and operator
Security - TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client - EZStation, UNV-Link, UNV-Link Pro
Web Browser - Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+

Interface

Audio I/O - 1 Input: impedance 1 kÎ©, amplitude 2.5 V [p-p], 1 Output: impedance 600 Î©, amplitude 2.5 V [p-p]
Alarm I/O - 2/1
Serial Port - 1 channel RS485 interface
Network - 1 Ã— RJ45 10 M/100 M/1000 M Base-TX Ethernet + 1 Ã— 100 M/1000 M SFP
Video Output - 1 BNC (For debugging)

Certification

EMC - CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Safety - CE LVD (EN 62368-1:2014+A11:2017) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment - CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

General

Power - DC12V(Â±25%), AC24V(Â±25%), PoE(IEEE 802.3af)
Power Consumption - Max 8W
Power Interface - Two-core terminal block
Dimensions - 6.0" x 2.8" x 2.6" (152 x 71 x 65 mm) (L x W x H) (excluding the lens)
Weight - 0.88lb (0.40kg)
Working Environment - -4 Â°F to 140 Â°F (-20 Â°C to 60 Â°C), Humidity: â‰¤ 95% RH (non-condensing)
Storage Environment - -40 Â°F to 158 Â°F (-40 Â°C to 70 Â°C), Humidity: â‰¤ 95% RH (non-condensing)
Surge Protection - 6 KV
Reset Button - Support
Web Client Language - 22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak
