IPC3224SS-ADF40K-I1 Uniview Prime II Series 2-in-1 4mm 20FPS @ 4MP IR Day/Night WDR Dome IP Security Camera 12VDC/PoE

SKU: IPC3224SS-ADF40K-I1

Brand: Uniview

High quality image with 2x4MP resolution, 1/3.0"CMOS sensor
Single IP with dual channels
25/20fps @ 4MP (2688x1520); 25/20fps @ 4MP(2560x1440); 30/25fps @ 3MP(2304x1296);30/25fps @ 2MP(1920 x 1080)
Ultra 265, H.264,H.265, MJPEG
Both channels support intelligent perimeter protection, include cross line, intrusion, enter area, leave area detection
Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and motor vehicle and non-motor vehicle
Intelligent People Flow Counting and Crowd Density Monitoring (Only Channel 1)
Complies with Section 889 of the NDAA

MPN: IPC3224SS-ADF40K-I1

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

Specifications

Camera

Lens

DORI

DORI Distance - Lens (mm) - 4.0, Detect (m) - 90.0m(295.3ft), Observe (m) - 36.0m(118.1ft) , Recognize (m) - 18.0m(59.1ft) , Identify (m) - 9.0m(29.5ft)

Illuminator

Video

Video Compression - Ultra 265, H.265, H.264, MJPEG
H.264 code profile - Baseline profile, Main profile, High profile
Frame Rate
- Main Stream - 25fps @ 4MP(2688x1520); 25fps @ 4MP(2560x1440); 30fps @ 3MP(2304x1296); 30fps @ 1080P (1920x1080),30fps @ 720P(1280x720)
- Sub Stream - 30fps @ 720P (1280 x 720); 30fps @ D1 (720x576); 30fps @ 640x360; 30fps @ 2CIF(704 x 288), 30fps @ CIF(352x288)
- Third Stream - 30fps @ D1 (720x576), 30fps @ 640x360; 30fps @ 2CIF(704x288), 30fps @ CIF(352x288)
Video Bit Rate - 128 Kbps~16 Mbps
U-code - Support
OSD - Up to 8 OSDs
Privacy Mask - Up to 4 areas
ROI - Up to 8 areas
Video Stream - Triple streams


White Balance - Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital Noise Reduction - 2D/3D DNR
Smart IR - Support
Flip - Normal/ Flip Vertical/ Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise
Dewarping - N/A
HLC - Support
BLC - Support
Defog - Digital Defog

Intelligent

Smart intrusion prevention - Support false alarm filtering: Line crossing detection, Intrusion detection, Enter Area detection, Leave Area detection
Recognition - Face capture(Only Channel 1)
Statistical Analysis - People counting, support people flow counting and crowd density monitoring(Only Channel 1)

Events

Basic Detection - Motion detection, Ultra motion detection, Tampering alarm, Audio detection
General Function - Watermark, IP address filtering, Tampering alarm, Access policy, ARP protection, RTSP authentication, User authentication

Audio

Storage

Network

Protocols - IPv4,IPv6, IGMP, ICMP ,ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, SSL/TLS, SSH
Compatible Integration - ONVIF (Profile S, Profile T, Profile G), API,SDK
User/Host - Up to 32 users. 3 user levels: administrator, common user and operator
Security - Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2 , WSSE and digest authentication for ONVIF
Client - EZStation, EZView, EZLive
Web Browser - Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above, Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above

Interface

Audio I/O - Input: impedance 35kΩ; amplitude 2V [p-p], Output: impedance 600Ω; amplitude 2V [p-p]
Alarm - I/O 1/1
Serial Port - N/A
Built-in Mic - Built-in two Mics
Built-in Speaker - N/A
WIFI - N/A
Network - 1 RJ45 10M/100M Base-TX Ethernet
Video Output - N/A

Certifications

EMC - CE-EMC (EN 55032, EN 61000-3-3,EN IEC 61000-3-2,EN 55035) FCC (FCC 47 CFR part15 B
Safety - CE-LVD (EN 62368-1) UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)
Environment - CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU)
Protection - IP67 (IEC 60529), IK10 (IEC 62262)

General

Power - DC 12V�25%, PoE (IEEE 802.3af)
Power consumption - Max 9.1w
Power Interface - � 5.5mm coaxial power plug
Dimensions - 6.9" x 4.1' x2.8" (176x104x72mm)
Weight - 1.37lb(0.62kg)
Material - Metal
Working Environment - -22°F ~ 140°F (-30°C ~ 60°C), Humidity: ≤95% RH (non-condensing)
Storage Environment - -22°F ~ 140°F(-30°C ~ 60°C), Humidity: ≤95% RH (non-condensing)
Surge Protection - 4KV
Reset Button - Support
