UAC-D122-APF28M Uniview 2.8mm 25FPS @ 2MP LightHunter Outdoor IR Day/Night DWDR Dome HD-TVI/HD-CVI/AHD/Analog Security Camera 12VDC

UAC-D122-APF28M is a 2MP LightHunter PoC fixed IR dome analog camera with a high-performance 1/2.9-inch CMOS sensor and 3D noise reduction technology. It supports TVI/AHD/CVI/CVBS, which effectively enhances product adaptability and diversity of networking solutions. With SYV-75-3 or other coaxial cable types, the camera can achieve low-cost, long-distance, and anti-interference mega-pixel HD video transmission without time delay. In addition, the PoC power supply system can achieve video and power transmission on one cable, simplifying wiring and installation work, and improving structural flexibility. It supports IR-cut filter with auto-switch (ICR) and provides color images at daytime and black/white images at night. The camera also supports audio input and synchronous transmission of audio and video.

Specifications

Sensor

• Pixel - 2MP
• Size - 1/2.9"
• Minimum illumination - 0.005 lux (F1.6, AGC ON), 0 lux (IR on)

Lens

• Lens - 2.8mm
• Lens mount - M12
• Angle of view - H: 101.5° V: 56.9° D: 117.4°

Illuminator

• Illuminator - One IR illuminator
• Illumination distance - 30m
• Lifetime - ≥60,000 hours

Video

• Resolution - 1080P: 1920(H)x1080(V), 720P: 1280(H) x720(V)
• Frame rate - TVI/AHD/CVI: 1080P@25fps (default), 1080P@30fps; 720P@25fps, 720P@30fps CVBS: PAL, NTSC
• Shutter time - PAL: 1/25s-1/50000s, NTSC: 1/30s–1/50000s


• Exposure mode - Four modes: Global (default), BLC, HLC, DWDR
• Day/Night - Three modes: Auto (default), Day, Night
• Noise reduction - 2D/3D
• White balance - Two modes: Auto (default), Manual
• WDR - DWDR
• Smart IR - Support
• Flip - Supports 180° horizontal flip, 180° vertical flip
• Defog - Digital Defog

Audio

• Microphone - Built-in Mic
• Camera audio - TVI: 1080P@30fps, 1080P@25fps, CVI: 1080P@30fps, 1080P@25fps

Interface

• Power - 5.5mm power interface
• Video output - BNC, supports TVI/AHD/CVI/CVBS

Operating environment

• Temperature - -22°F to 140°F (-30°C to 60°C)
• Humidity - ≤95% (RH, non-condensing)
• Surge protection - 4kV

General

• Power - DC 12V(±25%)/PoC, with reverse polarity protection, Max 3.3W
• Mount - Surface mount (default), optional tilted mounting bracket
• Dimensions - Φ109mmx83mm (diameterxheight)
• Material - Metal
• Weight - 0.86lb (390g)
• OSD menu language - 11 Languages, English, German, Spanish(Latin America), French, Italian, Japanese, Korean, Polish, Portuguese(Brazil), Russian, Turkish

Certification

• EMC - CE-EMC (EN 55032,EN 61000-3-3,EN IEC 61000-3-2,EN 55035), FCC (FCC 47 CFR part15 B)
• Safety - CE-LVD (EN 62368-1)
• Environment - CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU)
• Protection - IP67 (IEC 60529), IK10 (IEC 62262)

UAC-D122-APF28M Specifications PDF
