IP8365EH Vivotek 3~9mm Varifocal 30FPS @ 1920x1080 Outdoor IR Day/Night WDR Bullet IP Security Camera 12VDC/24VAC/POE - Extreme Weather

Specifications

System Information

• CPU - Multimedia SoC (System-on-Chip)
• Flash - 256 MB
• RAM - 384 MB

Camera Features

• Image sensor - 1/2.8" Progressive CMOS
• Maximum Resolution - 1920x1080 (2MP)
• Lens Type - Vari-focal, Remote Focus
• Focal Length - f = 3 ~ 9 mm
• Aperture - F1.2 ~ F2.3
• Auto-iris - P-iris
• Field of View - 39°~89° (horizontal), 22°~49° (vertical), 44°~103° (diagonal)
• Shutter Time - 1/5 sec. to 1/10,000 sec.
• WDR Technology - WDR Pro
• Day & Night - Removable IR-cut filter for day & night function, Smart IR Technology to avoid overexposure
• Minimum Illumination - 0.39 Lux @ F1.2, 50 IRE ( Color ), 0.001 Lux @ F1.2, 50 IRE ( B/W )
• Pan / Tilt / Zoom - ePTZ: 48x digital zoom (4x on IE plug-in,12x built in)
• IR Illuminators - Built-in IR illuminators, effective up to 30 meters, IR LED*4, with Smart IR Technology
• On-board Storage - SD/SDHC/SDXC card slot

Video

• Compression - H.264 & MJPEG
• Maximum Frame Rate - In both compression modes: 30 fps @ 1920x1080
• Maximum Streams - 2 simultaneous streams
• S/N Ratio - 62 dB
• Dynamic Range - 100 dB
• Video Streaming - Adjustable resolution, quality and bitrate
• Image Settings - Time stamp, text overlay, flip & mirror, configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks, scheduled profile settings, 3D Noise Reduction, EIS

Audio

• Audio Capability - Two-way audio (full duplex)
• Compression - AAC, G.711, G.726
• Interface - External microphone input, Audio output

Network

• Users - Live viewing for up to 10 clients
• Protocols - IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP
• Interface - 10 Base-T / 100BaseTX Ethernet (RJ-45)
• ONVIF - Supported, specification available at www.onvif.org

Intelligent Video

• Video Motion Detection - Triple-window video motion detection

Alarm and Event

• Alarm Triggers - Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection
• Alarm Events - Event notification using digital output, HTTP, SMTP, FTP and NAS server, File upload via HTTP, SMTP, FTP and NAS server

General

• Smart Focus System - Remote focus
• Connectors - RJ-45 for Network/PoE connection, Audio input/output, AV output, AC 24V power input, DC 12V power input, Digital input*1, Digital output*1
• LED Indicator - System power and status indicator
• Power input - DC12V/AC24V, IEEE 802.3af PoE

• Power consumption - DC Max. 30W (Heater on) 8W (Heater off) ,AC Max. 30W (Heater on) 8.8W (Heater off), PoE Max. 11W

• Dimensions - Ø: 85mm x 219 mm

• Weight - Net: 1,314g (Body only), Net: 1,911g (with stand and sunshield)

• Casing - Weather-proof IP67-rated housing

• Safety Certifications - CE, LVD, FCC Class A, VCCI, C-Tick, UL

• Operating Temperature - Starting Temperature: -40°C ~ 50°C (-40°F ~ 122°F), PoE: -10°C ~ 50°C (14°F ~ 122°F), Working Temperature: -50°C ~ 50°C (-58°F ~ 122°F

• Warranty - 24 months


System Requirements

• Operating System - Microsoft Windows 8/7/Vista/XP/2000
• Browser - Mozilla Firefox 7~10 (streaming only), Internet Explorer 7/8/9/10
• Other Players - VLC: 1.1.11 or above, QuickTime: 7 or above


IP8365EH Specifications PDF
