JP-DV Aiphone Vandal Resistant Video Door Station

The JP-DA is a surface mount plastic color video door station. The JP-DV is an aluminum die cast surface mount color video door station. The JP-DVF is a stainless steel flush mount color video door station. All of these units work with the JP Series and connect to the master station using an 18AWG 2-conductor solid core cable.

Specifications

• Power Source - Supplied from JP Series Master
• Communication - Hands-free
• Camera - CMOS
• Min. illumination - 5 lux
• Camera angle - Wide (approx. 170°) with digital PTZ
• Wiring - 2-conductor, PE insulation, Aiphone wire #871802
• Wiring Distance - 330'
• Operation Temp - 14~140° F (-10 ~ 60° C)
• Dimensions (HxWxD)
  • JP-DV - 6-13/16" x 3-7/8" x 1" (173 x 98 x 25 mm)
• Weight (approx)
  • JP-DV - 1.43lbs (650g)

JP-DV Specifications PDF

JP-DV Manual
