VAST-1CH Vivotek VAST VMS 1 Channel Add-on or 1 Channel 3rd Party License

Specifications

General

• Maximum Number of Cameras - Unlimited (Please Refer to System Requirements Below)
• Maximum Number of Servers - Unlimited (Please Refer to System Requirements Below)
• Maximum Number of Clients - Unlimited
• Support OS - Windows 8, 7, Vista, XP Windows Server 2012, 2008, 2003, 2000
• Support Web Browser -Automatic, Manual (2800K ~ 8500K)
• Mobile Support - iViewer (iOS/Android)
• Virtual Matrix Support - VAST Matrix (Please Refer to System Requirements Below)
• Devices Pack - .vdp File Update

LiveView (Local Display)

• Max. Channel - 64-Channel (with Dual Monitors)
• Layout - Multi Layout Display: 1x1, 2x2, 1+5, 3x3, 1+12, 4x4, 5x5, 1+31, 1P+2, 1P+6, 1P+8, 2V, 3V, 4V, 2V+3 Single Layout Display, Full Screen Display, Sequential Display
• Stream Application - Stream Selection & Auto Stream Size
• View Application - Drag & Drop Remote I/O Control PiP (Digital Zoom) Instant Replay De-interlace Video Display Mode (Aspect Ratio, Hide Borders, Keep Top/Down Borders)
• Fisheye Dewarp Mode - Fisheye Display Mode: Regular: 1O, 1P, 1R, 1O3R, 4R Wall Mount: 1P2R, 1P3R Ceiling/Floor Mount: 2P, 4R Pro, 1O8R

Playback

• Max. Channel - 16 Channels
• Layout - Multi Layout Display: 1x1, 2x2, 1+5, 3x3, 1+12, 4x4, 2V, 3V, 4V, 2V+3 Single Layout Display, Full Screen Display, Sequential Display
• Playback Mode - Asynchronous & Synchronous
• Playback Control - Play, Rewind, Pause, Stop, Next / Previous Video Start, Next / Previous Frame, 1/8X ~ 64X Speed Control, Bookmark
• Search Mode - Browsing, Date & Time (Fast), Event, Bookmark, Alarm, Log, Timeline, Timeline Scale

Video

• Video Format - MJPEG, MPEG4, H.264 AVC, H.264 SVC, H.265
• Video Resolution - Up to 9 Megapixels
• Video Enhancement - Basic Mode: Brightness, Contrast, Saturation, Hue Intelligent Mode: Defog, Rain, Snow, Fire / Smoke

Audio

• Audio Format - G.711, G.726, AMR, AAC
• Audio Capability - Two Way
• Audio Control - Mute, Broadcasting & Sound Play

Record

• Recording Time (sec.) - Pre-Record: 3-15, Post-Record: 10-60
• Recording Stream Type - Unicast
• Recording Stream - Single
• Recording Mode - Continuous, Schedule, Manual, Event, Activity Adaptive Streaming
• Recording Setting - Recycle (Unit: Size or Day)
• Recording File Format - 3 GP
• External Storage Recording - NAS (SMB & CIFS)

Alarm Management

• Alarm Period (sec.) - Max. 30
• Alarm Filter - Name, Time, Source, Event Type
• Alarm Setting - LiveView Alarm Notification: Fixed & Popup Alert Sound
• Schedule Type - Continuous, Schedule, Manual
• Camera Event - Motion, DI/O, Video Lost/Restore, PIR, Tampering, Temperature, IR, PPTZ, Line Crossing Detection, Loitering Detection, Field Detection
• Camera Status - Connection Status, Recording Status, Recording Error
• Substation - Substation Connection Status
• Storage Status - Storage Connection Status, Storage Capacity Status
• Station Status - License Status, Network Status, Virtual Memory Status
• External Devices Event - DI/O (With I/O Box)
• Action - Email, Start Recording, Set DO, GSM Short Message, HTTP & Client Notification

eMap

• Source - Import Picture
• Marked - Add, Remove, Direction Control, PTZ Control & Indicator LiveView
• Event Notification - Event Icon Light Flash

PTZ

• PTZ/ePTZ Control - Panel Control & Mouse Click Control
• PTZ/ePTZ Operation - Direction Control, Home, Zoom, Focus, Iris, Preset, Patrol (Group), Pan, Stop, Speed
• PTZ Operation Mode - Click to Move & Continuous Move

Export

• Print - Selection Windows & All Windows
• Snapshot - BMP & JPEG
• Export file - AVI, 3GP & EXE

Backup

• Schedule - NAS (SMB & CIFS)

System

• User Management - Authentication: Basic Account / Windows AD Account
• User Level - Administrator, Power User, User, Operator & Guest
• User Control - Permission, Accessible Cameras & Accessible Substation
• Date & Time - Sync PC
• Network - DDNS, SMTP, UPnP & Proxy
• Language - Czech, English, French, German, Italian, Japanese, Persian, Portuguese, Russian, Spanish, Simplified Chinese, Traditional Chinese

Device Integration

• Joystick - VIVOTEK USB Joystick All Windows™ Compatible USB Joystick
• I/O Box - Advantech ADAM-6000
• Switch - VIVOTEK VivoCam PoE Switch (AW-GEV Series)

Camera Integration

• Camera Insert - Manual & Search
• Basic Setting - User Name, Password & Camera Model Detection
• Connection Setting - Configuration Protocol: HTTP, HTTPS Streaming Protocol: TCP, UDP, HTTP, HTTPS
• Video Setting - Video Stream, Compression, Resolution, FPS, Video Quality
• Audio Setting - Compression & Bitrate
• Remote Focus - Manual Focus Adjustment & Full Range Scan
• NTP Setting - IP Address (NTP Server or VAST Server) & Updating Interval
• ONVIF Core Spec - Version 2.2 or above (By Project)
• ONVIF Stream - Video (H.264, MPEG4 & MJPEG) & Audio (G.711, One Way)
• ONVIF Recording - Continuous, Schedule, Manual
• ONVIF Control - PTZ Control (Up, Down, Left, Right & Zoom In/Out)
• ONVIF Discover - Discover the other brand camera through "Insert Camera & Batch Insert"

Advanced Feature

• VIVOTEK Exclusive Feature - Panoramic PTZ Seamless Recording

VAST-CHANNEL-LICENSE Specifications PDF
