[DISCONTINUED] CT-2M-P30FHIR Nuvico 4.3~129mm 30x Optical Zoom 30FPS @ 1080p Outdoor IR Day/Night WDR PTZ HD-TVI/AHD/Analog Security Camera 24VAC

Specifications

• Video Format - HD-TVI/AHD/CVBS
• Image Sensor - 1/2.8" SONY STARVIS CMOS sensor
• Resolution - HD-TVI : 1080p @ 25/30fps
• Video Output - HD-TVI, Analog, CVBS
• Lens Type (DC Auto Iris)
  • 30X A/F Optical Zoom 4.3mm~129.0mm
  • Auto Focus & Auto Iris
• Angle of View - 55.5°(W) ~ 3.0°(T)
• Day/Night Functionality - True D/N (Auto, Day, Night)
• Noise Reduction - 2DNR, 3DNR
• Exposure Control - Auto, Manual, Shutter Priority, lris Priority
• True WDR - 120dB
• Automatic Flip (180°) - Flip (Digital)
• Shutter Speed
  • 25/30fps - Auto (1/30,000~ x8 sec.), Manual
  • 50/60fps - Auto (1/50,000~ x8 sec.), Manual
• IR Illuminator - Synchronized IR LED & Fixed IR LED; Angle: 7° ~ 40°; Maximum 450ft indoor, 360ft outdoor range*
• Pan Range - 360° Endless
• Pan Speed - Max, 380°/sec. (Preset)
• Tilt Range - -10° ~ 190°
• Tilt Speed - Max, 380°/sec. (Preset)
• Auto Calibration - 0.1°~ 6°
• Auto Scan - 1 Auto Pan & 16 Auto Scans
• Preset - 240
• Tour - 8
• Pattern - 8
• Home Function - Yes
• Privacy Mask Zone - 8 Programmable Zones
• Alarm - 4 Inputs, 2 Outputs (Terminal Block)
• Control - RS-485, Baud Rate: 2400 ~ 38400 bps(Default: 9600bps)
• Operating Humidity - 0 ~ 90%RH (Non-condensing)
• Power Supply - 24VAC
• Power Consumption - 1.5A (22.0W) @ 24VAC
