FE9382-EHV Vivotek 1.47mm 30FPS @ 1920 x 1920 Outdoor Day/Night WDR Fisheye Panoramic IP Security Camera 12VDC/PoE - Extreme Weather

Specifications

System Information

• CPU -Multimedia SoC (System-on-Chip)
• Flash - 128 MB
• RAM - 512 MB

Camera Features

• Image sensor - 1/1.8" Progressive CMOS in 3096x2094
• Maximum Resolution - 1920x1920
• Lens Type - Fixed-focal
• Focal Length - f = 1.47 mm
• Aperture - F2.2
• Field of View - 180™ (horizontal) - 180™ (vertical) - 180™ (diagonal)
• Shutter Time - 1/5 sec. to 1/32,000 sec.
• WDR Technology - WDR Pro
• Day & Night - Removable IR-cut filter for day & night function
• Minimum Illumination - 0.18 Lux @ F2.2 (Color), 0.001 Lux @ F2.2 (B/W)
• Pan / Tilt / Zoom - ePTZ: 48x digital zoom (4x on IE plug-in, 12x builtin)
• On-board Storage - Slot type: MicroSD/SDHC/SDXC card slot Seamless Recording

Video

• Compression - H.265, H.264, MJPEG
• Maximum Frame Rate - H.265 & H.264: 30 fps @ 1920x1920 MJPEG: 12 fps @ 1920x1920
• Maximum Streams- 4 simultaneous streams
• S/N Ratio - 42.3 dB
• Dynamic Range - 100 dB
• Video Streaming - Adjustable resolution, quality and bitrate Smart Stream II
• Image Settings - Time stamp, text overlay, flip & mirror; Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks; Scheduled profile settings, 3D noise reduction; Adjustable image size, quality and bit rate, defog; Pixel counter

Audio

• Audio Capability - Two-way audio (full duplex)
• Compression - G.711, G.726
• Interface Built-in microphone, External microphone input, External line output
• Effective Range - 5 meters

Network

• Users - Live viewing for up to 10 clients
• Protocols - IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/ RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, SSL, TLS, NTCIP
• Interface - 10 Base-T/100 BaseTX Ethernet (RJ-45) *It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard
• ONVIF - Supported, specification available at www.onvif.org

Intelligent Video

• Video Motion Detection - Five-window video motion detection

Alarm and Event

• Alarm Triggers - Motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection, audio detection
• Alarm Events - Event notification using digital output, HTTP, SMTP, FTP, NAS server and SD Card File upload via HTTP, SMTP, FTP, NAS server and SD Card

General

• Connectors RJ-45 cable connector for Network/PoE connection Audio input*1 Audio output*1 DC 12V power input*1 Digital input*1 Digital output*1
• LED Indicator - System power and status indicator
• Power input - DC 12V IEEE 802.3af PoE Class 0
• Power consumption - Max. 20 W
• Dimensions - ™ 160 x 51 mm
• Weight - 762 g
• Casing - FE9382-EHV: Weather-proof IP66-rated housing Vandal-proof IK10-rated metal housing
• Safety Certifications CE, LVD, FCC Class A, VCCI, C-Tick, UL, EN50155
• Operating Temperature Starting Temperature: -13™F ~ 131™F Working Temperature: -40™F ~ 131™F
• Humidity - 90%
• Warranty - 36 Months

System Requirements

• Operating System - Microsoft Windows 7 / Vista / XP / 2000
• Web Browser - Mozilla Firefox 7~10 (Streaming only) Internet Explorer 7/8/9/10/11
• Other Players - VLC: 1.1.11 or above Quicktime: 7 or above

Included Accessories

• CD - User's manual, quick installation guide, Installation Wizard 2, VAST
• Others - Quick installation guide, warranty card, alignment sticker, desiccant bag, screw driver, screws pack, I/O cable, mounting bracket, software CD

FE9382-EHV Specifications PDF
