IPH2VD4-3-G Rainvision 2.8mm 30FPS @ 4MP Indoor/Outdoor IR WDR Day/Night Rugged Dome IP Security Camera 12VDC/PoE - Dark Gray

Specifications

Camera

• Image Sensor - 1/3" Progressive Scan CMOS
• Min. Illumination - Color: 0.01 Lux @ F1.2, AGC ON, 0.018 @ F1.6 AGC On, 0 Lux with IR
• Shutter Speed - 1/3 s to 1/100,000 s
• Lens - 2.8 Lens
• Day & Night - IR Cut Filter
• IR Range - 100'
• Digital Noise Reduction - 3D DNR
• WDR - 120dB
• 3-Axis Adjustment - Pan: 0° to 355°, Tilt: 0° to 75°, Rotate: 0° to 355°
• FOV - Horizontal: 103°, Vertical: 58°, Diagnol: 123°

Compression Standard

• Video Compression - H.265+ / H.265 / H.264+ / H.264 / MJPEG
• Type - Main Profile H.265 / H.264
• Video Bit Rate - 32 Kbps ~ 16 Mbps


• Max. Resolution - 2688 x 1520
• Main Stream - 50Hz:25fps (2688 x 1520, 2560 x 1440, 2304 x 1296, 1920 x 1080) 60Hz: 30fps (2688 x 1520, 2560 x 1440, 2304 x 1296, 1920 x 1080)
• Sub-stream - 50Hz: 25fps ( 640 x 480, 640 x 360, 320 x 240 ), 60Hz: 30fps ( 640 x 480, 640 x 360, 320 x 240 )
• Third Stream - 50Hz: 25fps ( 1280 x 720, 640 x 360, 352 x 288 ), 60Hz: 30fps ( 1280 x 720, 640 x 360, 352 x 240 )
• Image Setting - Rotate Mode, Saturation, Brightness, Contrast, Sharpness Adjustable by Client Software or Web Browser
• Image Enhancement - BLC/3D DNR/HLC
• Day/Night Switch - Auto/Schedule/Triggered by Alarm In

Network

• Network Storage - Micro SD/SDHC/SDXC card (128G), Local Storage and NAS (NFS, SMB/CIFS), ANR
• Alarm Trigger - Motion Detection, Video Tampering, Network Disconnected, IP Address Conflict, Illegal Login, HDD Full, HDD Error
• Protocols - TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
• General - One-key Reset, Dual-VCA, Anti-flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark, IP Address Filter
• API - ONVIF (Profile S, Profile G), ISAPI
• Interface - 1 RJ45 10M / 100M Self Adaptive Ethernet Interface
• Alarm Interface - 1 Input, 1 Output (max. 12 VDC, 30 mA), Terminal Bloc
• SVC - H.264 and H.265 Encoding

General

• Operating Conditions - -22 °F ~ 140 °F, Humidity 95% or less (non-condensing)
• Power Requirement - DC12V ± 25%, PoE (802.3af, class 4)
• Power Consumption - 12VDC Max. 6W PoE (802.3at, 37V-57V), 0.2A-0.1A, max. 7.5W
• Ingress Protection - IP67, IK10, TVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection
• Dimensions - Φ 4.4" x 3.2"
• Weight - 1.3 lbs
• Warranty - 3 Years
• Package Contents - Camera, Installation CD/Manual/Template, Mounting Screws, Weathertight Connector

IPH2VD4-3-G Specifications PDF
