IT9380-HF3 Vivotek 3.6mm 20FPS @ 5MP Indoor/Outdoor IR Day/Night WDR Pro Turret IP Security Camera PoE

Specifications

• Model - IT9380-H

• CPU - Multimedia SoC (System-on-Chip)
• Flash - 128MB
• RAM - 512MB

• Image Sensor - 1/2.7" Progressive CMOS
• Max. Resolution - 2560x1920 (5MP)
• Lens Type - Fixed-focal
• Focal Length - f = 3.6 mm
• Aperture - F2.0
• Audo-Iris - Fixed-iris
• Field of View - 76° (Horizontal), 59° (Vertical), 100° (Diagonal)
• Shutter Time - 1/5 sec. to 1/32,000 sec.
• WDR Technology - WDR Pro
• Day/Night - Yes
• Removable IR-cut filter - Yes
• IR Illuminators - Built-in IR illuminators, effective up to 30 meters with Smart IR, IR LED*2
• Minimum Illumination - 0.03 Lux @ F2.0 (Color), 0.005 Lux @ F2.0 (B/W), 0 Lux with IR illumination on
• Pan Range - 360°
• Tilt Range - 70°
• Rotation Range - 180°
• Pan/Tilt/Zoom Functionalities - ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
• On-board Storage - Slot type: MicroSD/SDHC/SDXC card slot Seamless Recording

• Compression - H.265, H.264, MJPEG
• Maximum Frame Rate - 20 fps @ 2560x1920
• Maximum Streams - 3 simultaneous streams
• S/N Ratio - 67dB
• Dynamic Range - 120 dB
• Video Streaming - Adjustable resolution, quality and bitrate, Smart Stream III
• Image Settings - Time stamp, text overlay, f lip & mirror; Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, priv acy masks; Scheduled prof ile settings, HLC, def og, 3DNR, v ideo rotation

• Audio Capability - One-way Audio
• Compression - G.711, G.726
• Interface - Build-in microphone
• Effective Range - 5 meters

• Users - Live viewing for up to 10 clients
• Protocols - 802.1X, ARP, CIFS/SMB, CoS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv 4, IPv 6, NTP, PPPoE, QoS, RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS, UDP, UPnP
• Interface - 10 Base-T/100 Base-TX Ethernet (RJ-45) *It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
• ONVIF - Supported, specification available at www.onvif.org

• Video Motion Detection - Five-window video motion detection
• VADP Package - Trend Micro IoT Security, Stratocast

• Alarm Triggers - Motion detection, periodical trigger, sy stem boot, recording notification, camera tampering detection, audio detection, manual trigger, SD card life expectancy, cyber security events (brute force attack event, cyber attack event, quarantine event)
• Alarm Events - Event notification using HTTP, SMTP, FTP, NAS server and MicroSD card File upload via HTTP, SMTP, FTP, NAS server and MicroSD card

• Connectors - RJ-45 cable connector for Network 10/100 Mbps PoE connection*1
• LED Indicator - System power and status indicator
• Power Input - IEEE 802.3af PoE Class 2
• Power Consumption - Max. 6 W (IR on), Max. 3.31 W (IR off)
• Dimensions - Ø 105 x 82.5 mm
• Weight - 475 g
• Casing - IP66, IK10 Metal Housing
• Safety Certifications - CE, FCC Class B, UL, LVD, VCCI, C-Tick
• Operating Temperature - Starting Temperature: -10°C ~ 50°C (14°F ~ 122°F), Working Temperature: -20°C ~ 50°C (-4°F ~ 140°F)
• Humidity - 90%
• Warranty - 24 months

• Operating System - Microsoft Windows 8/7 Mac 10.12 (Chrome only)
• Web Browser - Chrome 58.0 or above Internet Explorer 10/11
• Other Players - VLC: 1.1.11 or above, QuickTime: 7 or above

• Others - Quick installation guide, alignment sticker, screw pack, cable gland

IT9380-HF3 Specifications PDF
