060-2395/OR Vertical Cable 060-2395 Series 23 AWG 4 Unshielded Twisted Pair Solid Bare Copper CMR Non-Plenum Cat6 Cable - 1000' Pull Box - Orange

Specifications

• Part Number - 060-2395/OR

Technical Data

• Temperature Rating - 70 ºC
• Voltage Rating - 300 V
• Product Standard Certification - CMR
• NVP - 69%

Conductor

• Solid Bare Copper
• Size - 23 AWG

Insulation

• PE
• Average Thickness - 0.009 in. (0.22 mm)
• Min. Point Thickness - 0.007 in. (0.19 mm)
• Insulation Diameter - 0.04 in. (1.01 mm 0.005)
• Twisted Pair Diameter - 0.08 in. (2.02 mm ±0.01)

Seperator

• PP

Assembly Diameter

• 0.2 in. (5.00 mm)

Jacket

• PVC
• Average Thickness - 0.024 in. (0.60 mm)
• Min. Point Thickness - 0.02 in. (0.50 mm)
• Outer Diameter - 0.24 in. (6.20 mm ±0.1)
• Rip Cord - Yes

Color of Pairs

• Pair 1 - Blue,White-Blue
• Pair 2 - Orange,White-Orange
• Pair 3 - Green,White-Green
• Pair 4 - Brown,White-Brown

Mechanical Characteristics

• Test Object - Jacket
• Test Material - PVC
• Before
  • Tensile Strength (Mpa) - >=13.8
  • Aging Elongation (%) - >=100
  • Aging Condition (ºCxhrs) - 100x168
• After
  • Tensile Strength (Mpa) - >=85% of unaged
  • Aging Elongation (%) - >=50% of unaged
  • Cold Bend (-20±2º Cx4hrs) - No Crack

Marking on Jacket

• E502490 (UL)c(UL) CMR 75C UTP 4PR 23AWG FT4 550MHz CAT6 ANSI/TIA-568.2-D RoHS XXXXFT

Electrical Characteristics

• 1.0-100MHz Impendance (Ohms) - 100±15
• 100-250MHz Impendance (Ohms) - 100±25
• 250-550MHz Impendance (Ohms) - 100±35
• 1.0-250MHz Delay Skew (ns/100m) - <=45
• Pair-to-Ground Capacitance Unbalance (pF/100m) - <=330
• Max. Conductor DC Resistance 20°C (ohms/km) - 95
• Resistance Unbalance (%) - <=5
