NVR302-16S2-P16-4TB Uniview Easy S2-P Series 16 Channel NVR 160Mbps Max Throughput - 4TB with Built-in 16 Port PoE

Specifications

Video/Audio Input

• IP Video Input - 16-ch
• Two-way Audio Input - 1-ch, RCA

Network

• Incoming Bandwidth - 320Mbps
• Outgoing Bandwidth - 320Mbps
• Remote Users - 128
• Protocols - TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS,DNS,DDNS,SNMP,SMTP,NFS

Video/Audio Output

• HDMI/VGA Output - VGA: 60Hz @ (1920x1080p), 50Hz @ (1920x1080p), 60Hz @ (1600x1200), 60Hz @ (1280x1024), 60Hz @ (1280x720), 60H @ (1024x768), HDMI : 30Hz @ 4K (3840x2160), 60Hz @ (1920x1080p), 50Hz @ (1920x1080p), 60Hz @ (1280x1024), 60Hz @ (1280x720), 60H @ (1024x768)
• Recording Resolution - 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
• Audio Output - 1-ch, RCA
• Audio Compression - G.711A, G.711U
• Synchronous Playback - 16-ch
• Live View Display - 1/4/6/8/9/16
• Corridor Mode Screen - 3/4/5/7/9/10/12/16

Snapshot

• FTP/Schedule/Event Snapshot - 16-ch snapshot, up to 1080P resolution

Decoding

• Decoding format - Ultra 265, H.265, H.264
• Live View/Playback - 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
• Capability - 1 x 12MP@30, 2 x 4K@30, 5 x 4MP@30, 10 x 1080P@30, 16 x 720P@30

Hard Disk

• SATA - 2 SATA interfaces
• Capacity - up to 10TB for each HDD
• eSATA - NA
• Disk Group - Support

General Alarm

• General Alarm - Motion, Tampering, Human Body Detection, Video Loss, Input Alarm, Audio Detection
• Alert Alarm - IP Conflict, Network Disconnected, Disk Offline , Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal

External Interface

• Network Interface - 1 RJ45 10M/100M/1000M self-adaptive Ethernet Interfaces
• USB Interface - Front panel: 1 x USB2.0, Rear panel: 1 x USB3.0
• RS232 - NA
• RS485 - 1
• Alarm In - 8-ch
• Alarm Out - 2-ch

PoE

• Interface - 16 RJ-45 10M/100M self-adaptive Ethernet Interface
• Max Power - Max 30W for single port, Max 240W in total
• Supported Standard - IEEE 802.3af/at

General

• Power Supply - 100~240V AC, Power Consumption: ≤ 15 W (without HDD)
• Working Environment - +14°F~+131°F (-10°C~+ 55°C), Humidity ≤ 90% RH (non-condensing)
• Dimensions (WxDxH) - 15.0" x 12.4" x 2.1" (380mm x 315mm x 53mm)
• Weight (without HDD) - ≤5.73lb (2.6Kg)

Certification

• Certification - UL, CE, FCC, RoHS, WEEE

NVR302-16S2-P16-4TB Specifications PDF
