XNP-C9310R Hanwha Vision X Series 6.91mm-214.64mm 31x Optical Zoom 30FPS @ 4K Indoor/Outdoor IR Day/Night WDR PTZ IP Security Camera POE

Introduction

Enhance your vision

Hanwha Vision AI Focus PTZ cameras pair traditional pan, tilt, zoom functionality with intelligent quick zoom, focus and auto-tracking technology for an advanced video surveillance solution.

Specifications

Video

• Imaging Device - 1/1.8" CMOS
• Resolution - 3840x2160, 2592x1944, 2592x1464, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
• Max. Framerate - H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz) (@8MP Max. 5fps)
• Min. Illumination - Color: 0.06 Lux(F1.36, 1/30sec, 30 IRE) BW: 0.006 Lux(F1.36, IR LED Off), 0Lux (IR LED On)

Lens

• Focal Length (Zoom Ratio) - 6.91 ~ 214.7mm(31x) zoom (digital 32x, total 992x zoom) Support Quick zoom
• Max. Aperture Ratio - F1.36(Wide)~F4.6(Tele)
• Angular Field of View - H : 60.6°(Wide)~2.59°(Tele) V : 35.1°(Wide)~1.45°(Tele) D : 68.8°(Wide)~2.97°(Tele)
• Min. Object Distance - 3m(9.84ft)
• Focus Control - Oneshot AF, Focus save, Focus scan, Wise auto focus
• Lens Type - P-iris(IR corrected)

Pan / Tilt / Rotate

• Pan/Tilt/Rotate Range - 360° Endless
• Pan Speed - Preset: 550°/sec, Manual: 0.024°/sec~200°/sec
• Tilt Range - 110° (90° ~ -20°)
• Tilt Speed - Preset: 550°/sec, Manual: 0.024°/sec~200°/sec
• Sequence - Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule
• Preset Accuracy - ±0.07° (±20°C by temperature at preset setting)

Operational

• Camera Title - Displayed up to 85 characters
• Direction Indicator - Support
• Day & Night - Auto(ICR)
• Backlight Compensation - BLC, HCL, WDR, SSDR
• Wide Dynamic Range (dB) - 120
• Digital Noise Reduction - WiseNRâ…¡(Based on AI engine), SSNRâ…¤
• Digital Image Stabilization - Support(built-in gyro sensor)
• Defog - Support
• Motion Detection - 8ea, 8 Point Polygonal zones
• Privacy Masking - 32ea, 4point Quadrangle zones - Color: Gray/Green/Red/Blue/Black/White - Mosaic
• Gain Control - Off / Max gain / Manual
• White Balance - ATW / NarrowATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium
• Electronic Shutter Speed - Minimum / Maximum / Anti flicker (2~1/12,000sec) Prefer shutter control(Based on AI engine)
• Video Rotation - Flip&Mirror
• Analytics - Classified object type : Person/Face/Vehicle/License plate Attributes : Vehicle(Type:car/bus/truck/motorcycle/bicycle) Support DetectionShot Analytics events based on AI engine - Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit) Analytics events - Motion detection, Tampering, Fog detection, Shock detection, Virtual area(Appear/Disappear) * Audio detection, Sound classification(Via optional I/O box SPM-4210)
• Alarm Triggers - Analytics, Network disconnect, Alarm input((Via optional I/O box SPM-4210), Time schedule, MQTT subscription
• Alarm Events - When alarm trigger occurred - File upload(image) : e-mail/FTP - Notification : e-mail - Recording : SD/SDHC/SDXC or NAS recording at event triggers - Handover: PTZ preset, send message by HTTP/HTTPS/TCP - MQTT: publication * Alarm output / Audio clip playback(Via optional I/O box SPM-4210)
• Light Type - IR LED (850nm)
• IR Viewable Length - Wise IR 250m(820ft)
• Water Removal - Support(Spin dry, Lens heater)
• Auto Tracking - Support Object auto tracking(Person/Vehicle) Target lock tracking

Network

• Ethernet - Metal shielded RJ-45(10/100BASE-T)
• Video Compression - H.265/H.264: Main/Baseline/High, MJPEG
• Smart Codec - Manual(5ea area), WiseStreamâ…¡, WiseStreamâ…¢(Based on AI engine)
• Video Quality Adjustment - H.264/H.265: Target bitrate level control MJPEG: Target bitrate level control
• Bitrate Control - H.264/H.265: CBR or VBR MJPEG: VBR
• Streaming - Unicast(20 users) / Multicast/ Multiple streaming(Up to 10 profiles)
• Protocol - IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast) , NTCIP 1205, MQTT
• Application Programming Interface - ONVIF Profile S/G/T SUNAPI(HTTP API) Hanwha Vision open platform

Security

• OS / Firmware Protect - Secure boot, Signed firmware, Firmware encryption
• User authentication - Digest Authenticaton, Prevent brute-force attack
• Network authentication - 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
• Secure Communication - HTTPS, SRTP, WSS(Websocket secure)
• Access Control - Access control based on IP address
• Data Protect - Authentication information encryption, ZIP compression encryption
• Audit - User Access/System/Event log management
• Device ID - Device certificate(Hanwha Vision Root CA)
• Secure Storage - TPM(Trusted platform module), HTPM(Hanwha trusted platform module), SDcard partition encrypt
• Security Certificate - TPM with FIPS 140-2 level 2

General

• Webpage Language - English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
• Memory - RAM 4GB, Flash 512MB
• Edge Storage - Micro SD/SDHC/SDXC 2slot 1TB (512MBx2)

Environmental & Electrical

• Operating Temperature / Humidity - Normal : -50°C~+55°(-58°F ~ +131°F)/ +74°C(165°F)(Max) based on NEMA TS-2(2.2.7) * Start up should be done at above -30°C 0~95% RH(Non-condensing)
• Storage Temperature / Humidity - -50°C ~ +60°C(-58°F ~ +140°F) / 0~90% RH
• Certification - IP66/IP67, IK10, NEMA4X Safety(UL, KC-SDOC), EMC(FCC, CE, VCCI, RCM, KC) NEMA-TS 2(2.2.7, 2.2.8, 2.2.9)
• Input Voltage - HPoE(IEEE802.3bt type4, Class8, Injector included)
• Power Consumption - HPoE: Max 62W, typical 23W

Mechanical

• Color / Material - White / Aluminum
• RAL Code - RAL9003
• Product Dimensions / Weight - ø188x264.9mm(ø7.40x10.47") / 4400g (9.70lb)
• Hanging Mount (Dome) - SBP-156HMW
• Ceiling Mount (Assy) - SBP-156CMW, SBP-300CMTS, SBP-300CMW1/900CMW, SBP-150CMI/300CMI
• Wall Mount - SBP-156WMW, SBP-390WMW2
• Pole Mount - SBP-300PMW2
• Parapet Mount - SBP-156LMW, SBP-300LMW
• Corner Mount - SBP-156KMW, SBP-300KMW1
• Cabinet - SBP-300NBW

Certifications & Standards

• EMC - FCC 47 CFR 15 Subpart B Class A ICES-3(A)/NMB-3(A) CE/UKCA - EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3 VCCI CISPR 32 Class A RCM AS/NZS CISPR 32 Class A KS C 9832 Class A , KS C 9835
• Safety - UL 62368-1, CAN/CSA C22.2 NO. 62368-1 IEC/EN 62471
• Environment - IEC/EN 63000 IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10 NEMA TS 2-2013 (2.2.7, 2.2.8, 2.2.9) NEMA 250 type 4X

DORI (EN62676-4 standard)

• Detect (25PPM/ 8PPF) - Wide: 131.4m(431.19ft) / Tele: 3397.3m(11146.16ft)
• Observe (63PPM/ 19PPF) - Wide: 52.6m(172.48ft) / Tele: 1358.9m(4458.46ft)
• Recognize (125PPM/ 38PPF) - Wide: 26.3m(86.24ft) / Tele: 679.5m(2229.23ft)
• Identify (250PPM/ 76PPF) - Wide: 13.1m(43.12ft) / Tele: 339.7m(1114.62ft)

Ver

• Ver - 202311
