SHD-1372FPW Hanwha Vision In-Ceiling Housing

There are currently no active sales or promotions related to this item.

SKU: SHD-1372FPW

Brand: Hanwha Vision

Features:

Plenum-rated In-ceiling Mount compatible with PND-A7082RV, PND-A9082RV, PND-A6081R, PND-A9081R, XND-6083RV, XND-8083RV, XND-8093RV, XND-9083RV

More details...

There are currently no active sales or promotions related to this item.

MPN: SHD-1372FPW
EAN: 8801089233578

Quantity:

Add to List

Already a DWG Dealer? - Sign In to view pricing.

Product Details

Specifications

Mechanical

Color - White
Material - Aluminum
RAL code - RAL9003
Product dimensions / weight - ø352x107.4mm(ø13.86x4.23") / 2450g(5.40lb)
Tile thickness - 10~70mm(0.4~2.8")
Mount Screw size - TR20
Max. load - 5Kg(11.02lb) * Maximum load of ceiling board: 11.6kg(25.60lb)
Conduit hole - 19.1mm(3/4")(M25), 12.7mm(1/2")(M20)
Supported products - PND-A7082RV, PND-A9082RV, PND-A6081R, PND-A9081R, XND-6083RV, XND-8083RV, XND-8093RV, XND-9083RV

SHD-1372FPW Specifications PDF
