PNB-A6001 Hanwha Techwin 120FPS @ 2MP Outdoor Day/Night WDR Box IP Security Camera 12VDC/POE - No Lens

Specifications

Video

• Imaging Device - 1/2" CMOS
• Resolution - 1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360
• Max. Framerate - H.265/H.264: 60fps (AI analytics on), 120fps (AI analytics off), MJPEG: 15fps
• Min. Illumination
  • Color: 0.006Lux(F1.2, 1/30sec,30IRE) B/W : 0.0006Lux(F1.2, 1/30sec,30IRE), 30fps
  • Color: 0.012Lux(F1.2, 1/60sec,30IRE) B/W : 0.0012Lux(F1.2, 1/60sec,30IRE), 60fps
  • Color: 0.024Lux(F1.2, 1/120sec,30IRE) B/W : 0.0024Lux(F1.2, 1/120sec,30IRE), 120fps
• Video Out - CVBS: 1.0 Vp-p / 75Ω composite, 720x480 for installation, USB: Micro USB Type B, 1280x720 for installation

Lens

• Focus Control - Simple focus
• Lens Type - DC auto iris, P iris, Manual, I-CS
• Mount Type - C mount, CS mount

Operational

• Camera Title - Displayed up to 85 characters
• Day & Night - Auto(ICR)
• Backlight Compensation - BLC, WDR, SSDR
• Wide Dynamic Range - 120dB
• Digital Noise Reduction - SSNR, WiseNR Ⅱ (using AI engine)
• Digital Image Stabilization - Stabilization Support(built-in gyro sensor)
• Motion Detection - 8ea, polygonal zones
• Privacy Masking - 6ea, rectangle zones: Color: Gray/Green/Red/Blue/Black/White
• Gain Control - Low / Middle / High
• White Balance - ATW / AWC / Manual / Indoor / Outdoor
• LDC - Support
• Electronic Shutter Speed - Minimum / Maximum / Anti flicker (1/5~1/12,000sec), Auto prefer shutter control based on AI engine
• Video Rotation - Flip, Mirror, Hallway view (90°/270°)
• Analytics
  • Classified object type : Person/Face/Vehicle/License plate with attributes, BestShot per object
  • Analytics events based on AI engine : Object detection, Face mask detection, Directional detection, Digital auto tracking, Enter/Exit, Loitering, Virtual line, Social distancing detection
  • Analytics events : Defocus detection, Motion detection, Appear/Disappear, Tampering, Audio detection, Sound classification, Shock detection
• Business Intelligence - People counting, Queue management, Heatmap based on AI engine
• Serial Interface - RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell)
• Alarm I/O - Input 1ea / Output 1ea / DC 12V Power (Max. 50mA) 1ea
• Alarm Triggers - Analytics, Network disconnect, Alarm input
• Alarm Events
  • File upload via FTP and e-mail
  • Notification via e-mail
  • SD/SDHC/SDXC or NAS recording at event triggers
  • Alarm output
  • Handover
  • Audio playback
• Audio In - Selectable(microphone in/line in/Built in microphone), Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
• Audio Out - Line out, Max.output level: 1Vrms

Network

• Ethernet - Metal shielded RJ-45(10/100/1000 BASE-T)
• Video Compression - H.265/H.264: Main/High, MJPEG
• Audio Compression
  • G.711 u-law /G.726 Selectable
  • G.726(ADPCM) 8KHz, G.711 8KHz
  • G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
  • AAC-LC: 48Kbps at 16KHz
• Smart Codec - Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ (using AI engine)
• Bitrate Control - H.264/H.265: CBR or VBR, MJPEG: VBR
• Streaming - Unicast(6 users) / Multicast, Multiple streaming(Up to 5 profiles)
• Protocol - IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast)
• Security
  • HTTPS(SSL) Login Authentication
  • Digest Login Authentication
  • IP Address Filtering
  • User access log
  • 802.1X Authentication (EAP-TLS, EAP-LEAP)
  • Device Certificate (Hanwha Techwin Root CA)
  • TPM with FIPS 140-2 level 2
  • Secure boot, Verify firmware forgery
• Application Programming Interface
  • ONVIF Profile S/G/T
  • SUNAPI(HTTP API)
  • Wisenet open platform

General

• Webpage Language - English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek Micro
• Edge Storage - Micro SD/SDHC/SDXC 2 slots, maximum 512GB each
• Memory - 4096MB RAM, 512MB Flash

Environmental & Electrical

• Operating Temperature / Humidity - +14°F ~ +131°F (-10°C ~ +55°C) / Less than 90% RH
• Storage Temperature / Humidity - -58°F ~ +140°F (-50°C ~ +60°C) / Less than 90% RH
• Input Voltage - PoE+(IEEE802.3at), 12VDC
• Power Consumption - PoE+: Maximum 17.5W, Typical 13.7W, 12VDC: Maximum 14W, Typical 10.6W

Mechanical

• Color / Material - Body: Black / Aluminum
• Product Dimensions / Weight - 3.19x2.64x6.48" (81x67x165mm), Weight : 1.94lb (0.88kg)

PNB-A6001 Specifications PDF
